In this mode, compensations in all three geometry axes can be configured through
multiple programming, i.e. through the activation of one component, the length
compensation possibly active in another axis is not deleted.
2: Mode C
The tool length acts, independent of the active plane, on the axis that has
simultaneously been programmed with H. Otherwise, the response is the same as with
mode B.
20382 TOOL_CORR_MOVE_MODE C01, C08 -
- Traversing of tool length compensation BOOLEAN Reset
-
- - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
Description: This machine data determines how the tool length compensations are traversed.
0: A tool length compensation is only traversed if the associated axis has been
programmed (behavior as in previous software versions)
1: Tool lengths are always traversed independently of whether the associated axes
are programmed or not.
20384 TOOL_CORR_MULTIPLE_AXES C01, C08, C11 -
- Tool length compensation in several axes simultaneously BOOLEAN Reset
-
- - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
Description: This machine data determines for tool length compensation in ISO dialect M (ISO2)
(G43 / G44),
whether the compensation shall be allowed in mode C (selection of the axis
on which the compensation is acting by specifying the corresponding axis letter) to
act on several axes simultaneously.
If this machine data is 1, this type of programming is allowed; otherwise it is
rejected with an alarm.
20443 LOOKAH_FFORM EXP, C05 -
- Activate extended LookAhead BYTE NEW CONF
-
808d-me42 5 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 2 0/0 S
808d-me62 5 0, 0, 1, 1, 1 0 2 2/2 M
808d-te42 5 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 2 0/0 S
808d-te62 5 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 2 0/0 S
808d-mte40 5 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 2 7/2 M
808d-mte60 5 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 2 7/2 M
Description: The MD specifies for which technology groups the extended LookAhead is active.
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 145
