808d-mte40 5 1., 1., 1., 1., 1., 1., 1.,
1., 1., 1., 1., 1., 1., 1.,
1., 1., ...
0.0 - 1/1 M
808d-mte60 5 1., 1., 1., 1., 1., 1., 1.,
1., 1., 1., 1., 1., 1., 1.,
1., 1., ...
0.0 - 1/1 M
Description: Factor to determine the degree of smoothing and torsion.
A larger value of this MD causes a stronger smoothing and thus a more homogenous
curvature/torsion and resulting path velocity.
With this factor being zero no smoothing is performed.
There is an entry for all dynamic G code groups.
20606 PREPDYN_SMOOTHING_ON EXP, C05 B1
- Activation of curve smoothing BOOLEAN NEW CONF
-
808d-me42 5 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 - 1/1 M
808d-me62 5 0, 0, 1, 1, 1 0 - 1/1 M
808d-te42 5 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 - 0/0 S
808d-te62 5 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 - 0/0 S
808d-mte40 5 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 - 7/2 M
808d-mte60 5 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 - 7/2 M
Description: Switch on of curve and torsion smoothing.
Smoothing of the curve or torsion causes a homogenous path velocity.
Smoothing is only performed, when the relevant factor is MD 20605
$MC_PREPDYN_SMOOTHING_FACTOR > 0.
There is an entry for all dynamic G code groups.
20620 HANDWH_GEOAX_MAX_INCR_SIZE C08, C06 H1
mm Limitation handwheel increment for geometry axes DOUBLE PowerOn
-
- - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
0.0 - 1/1 M
Description: > 0: Limitation of the size of the selected increment for geometry axes
MD 11330 $MN_JOG_INCR_SIZE0[<increment/VDI signal>] or
SD41010 $SN_JOG_VAR_INCR_SIZE for geometry axes
0: No limitation on geometry axes
20622 HANDWH_GEOAX_MAX_INCR_VSIZE C08, C06, C05 -
mm/min Path velocity override DOUBLE PowerOn
-
808d-me42 - 500., 500., 500., 500.,
500., 500., 500., 500....
0.0 - 0/0 S
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 155
