808d-me62 - 500., 500., 500., 500.,
500., 500., 500., 500....
0.0 - 0/0 S
808d-te42 - 500., 500., 500., 500.,
500., 500., 500., 500....
0.0 - 0/0 S
808d-te62 - 500., 500., 500., 500.,
500., 500., 500., 500....
0.0 - 0/0 S
808d-mte40 - 500., 500., 500., 500.,
500., 500., 500., 500....
0.0 - 7/2 M
808d-mte60 - 500., 500., 500., 500.,
500., 500., 500., 500....
0.0 - 7/2 M
Description: The following applies to the velocity override of the path:
> 0: Limitation of the size of the selected increment
(MD11330 $MN_JOG_INCR_SIZE_[<increment/VDI signal>] or
SD41010 $SN_JOG_VAR_INCR_SIZE) / 1000*IPO sampling time
= 0: No limitation
20624 HANDWH_CHAN_STOP_COND EXP, C09 H1, P1
- Definition of response of handwheel travel, channel-specific DWORD PowerOn
-
808d-me42 - 0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF...
0 0x1FFFF 2/2 M
808d-me62 - 0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF...
0 0x1FFFF 2/2 M
808d-te42 - 0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF...
0 0x1FFFF 2/2 M
808d-te62 - 0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF...
0 0x1FFFF 2/2 M
808d-mte40 - 0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF...
0 0x1FFFF 7/2 M
808d-mte60 - 0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF,
0x13FF, 0x13FF...
0 0x1FFFF 7/2 M
Description: Definition of the response for handwheel travel to channel-specific VDI interface
signals (bit 0 to bit 7) or CP-SW limit stop or stop by an OEM application (bit 7):
Bit = 0:
Interruption or collection of the displacements entered via the handwheel.
Bit = 1:
Traversing canceled and no collecting.
Bit assignment:
Bit 0: Mode group stop
Bit 1: Mode group stop, axes plus spindle
Bit 2: NC stop
Bit 3: NC stop, axes plus spindles
Machine data
3.3 Channel-specific machine data
Parameter Manual
156 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
