1:
With M96 Pxx, CYCLE396.spf is always called in the case of an interrupt
Bit11: 0:
With G54 Pxx, only G54.1 is displayed
1:
With G54 Pxx, the programmed program is displayed after the point, e.g. G54.48
Bit12: 0:
When the subroutine defined with M96 Pxx is called, $P_ISO_STACK is not modified
1:
When the subroutine defined with M96 Pxx is called, $P_ISO_STACK is incremented
Bit13: 0:
G10 is executed without internal STOPRE
1:
G10 is executed with internal STOPRE
Bit14: 0:
ISO_mode T: No alarm if a cutting edge has been programmed in the T command.
1:
ISO mode T: Alarm 14185 if a cutting edge has not been programmed in
the T command.
Bit 15: 0:
ISO_mode M: G51 Scale, the axial scale factors I, J, K work with 'pocket calculator
notation' as programmed.
1:
ISO_mode M: G51 Scale, the axial scale factors I, J, K with 'pocket calculator
notation', are multiplied by the value in MD22910 $MC_WEIGHTING_FACTOR_FOR_SCALE.
20750 ALLOW_G0_IN_G96 C09, C05 P2, V1
- G0 logic with G96, G961 BOOLEAN PowerOn
-
- - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
Description: This machine data defines the speed regulation characteristic of the spindle in G0
blocks with constant cutting rate (G96, G961) selected .
1: In a G0 block, the spindle speed is kept constant at the last value of the
previous block that was unequal G0.
Prior to a subsequent block that does not contain G0, the spindle speed is increased
to a value that belongs to the transverse axis position of the subsequent block.
0: In a G0 block, the spindle speed changes against the transverse axis position.
20800 SPF_END_TO_VDI C04, C03 H2, K1
- End of subroutine to PLC BYTE PowerOn
-
- - 1, 1, 1, 1, 1, 1, 1, 1... - - 1/1 M
Description: Bit 0 = 1:
The M functions for subroutine end (M17 and/or M2/M30) are transferred to the PLC
interface.
Bit 0 = 0:
The M functions for subroutine end (M17 and/or M2/M30) are not transferred to the PLC
interface.
Note:
Machine data
3.3 Channel-specific machine data
Parameter Manual
160 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
