21202 LIFTFAST_WITH_MIRROR C09 K1
- Rapid retract with mirrorring BOOLEAN PowerOn
-
808d-me42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-me62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-te42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-te62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-mte40 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/2 M
808d-mte60 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/2 M
Description: 1: When determining the retraction direction, if mirroring of the contour is active
then the retraction direction is also mirrored. Mirroring of the retraction direction
only refers to the directional components vertical to the tool direction.
0: Mirroring of the contour is NOT taken into account when determining the
retraction direction.
21204 LIFTFAST_STOP_COND C09 M3
- Stop behavior with fast retraction DWORD NEW CONF
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF ReadOnly M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF ReadOnly M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF ReadOnly M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF ReadOnly M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF 7/2 M
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF 7/2 M
Description: Specifies the stop behavior of the liftfast motion under different stop conditions
Bit0: Axial NC/PLC interface signal DB380x DBX4.3 (Axial feed stop / Spindle stop) or
CP-SW limit stop or a stop by an OEM application
=0 Stop of the retraction motion in case of an axial feed stop or CP-SW limit stop or
stop by an OEM application
=1 No stop of the retraction motion in case of an axial feedstop or CP-SW limit stop
or stop by an OEM application
Bit1: Feed disable in channel NC/PLC interface signal DB3200 DBX6.0 (Feed stop)
=0 Stop of the retraction motion in case of a feed stop in the channel
=1 No stop of the retraction motion in case of a feed stop in the channel
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 165
