Siemens SINUMERIK 808D ADVANCED Parameter Manual

Description: JOG velocity for geometry axes in the channel (mm/min)
21186 TOCARR_ROT_OFFSET_FROM_FR C01, C07 F2
- Offset of TOCARR rotary axes from WO BOOLEAN Immediately
-
808d-me42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-me62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-te42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-te62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-mte40 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/2 M
808d-mte60 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/2 M
Description: Rotary axes offset for the orientable tool holder is automatically accepted from the
work offset activated
on activation of the orientable tool holder for the rotary axes.
21200 LIFTFAST_DIST C09 K1, V1, 2.6, 6.1
mm Traversing distance on rapid lift from contour DOUBLE PowerOn
-
808d-me42 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.0 - ReadOnly M
808d-me62 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.0 - ReadOnly M
808d-te42 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.0 - ReadOnly M
808d-te62 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.0 - ReadOnly M
808d-mte40 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.0 - 7/2 M
808d-mte60 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.0 - 7/2 M
Description: The machine data determines the absolute value of the traverse movement for rapid
lift. The direction of the traverse movement is defined in the part program by the
command ALF.
References:
/PA/, Programming Guide: Fundamentals
Machine data
3.3 Channel-specific machine data
Parameter Manual
164 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
