See MD10715 $MN_M_NO_FCT_CYCLE
Related to:
MD10714 $MN_M_NO_FCT_EOP,
MD10715 $MN_M_NO_FCT_CYCLE,
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR,
MD22254 $MC_AUXFU_ASSOC_M0_VALUE
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE,
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
22256 AUXFU_ASSOC_M1_VALUE C01, C03, C10 H2
- Additional M function for conditional stop DWORD PowerOn
-
- - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 2/2 M
Description: This machine data defines an additional, predefined M function, which behaves in the
same way as M1. The value of the machine data corresponds to the number of the
auxiliary M function.
Predefined M numbers, such as M0, M1, M2, M3, etc., are not allowed.
Restriction:
See MD10715 $MN_M_NO_FCT_CYCLE
Related to:
MD10714 $MN_M_NO_FCT_EOP,
MD10715 $MN_M_NO_FCT_CYCLE,
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR,
MD22254 $MC_AUXFU_ASSOC_M0_VALUE
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE,
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
22400 S_VALUES_ACTIVE_AFTER_RESET C04, C03, C05 -
- S function active beyond RESET BOOLEAN PowerOn
-
- - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 2/2 M
Description: 1: The last S values set in the main run are still active after a RESET.
This also applies to the dynamic correction values ACC, VELOLIM in spindle mode.
0: The various S values are equal to 0 after a RESET, and must therefore be
reprogrammed.
The dynamic correction values ACC and VELOLIM are reset to 100% for spindle mode if
the axis-specific MD35040 $MA_SPIND_ACTIVE_AFTER_RESET and MD32320
$MA_DYN_LIMIT_RESET_MASK do not specify anything else.
Note:
The values for ACC and VELOLIM are also retained for spindle mode if MD35040
$MA_SPIND_ACTIVE_AFTER_RESET is not equal to zero or the axis-specific MD35040
$MA_SPIND_ACTIVE_AFTER_RESET is not equal to zero.
Machine data
3.3 Channel-specific machine data
Parameter Manual
170 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
