22702 TRACE_STARTTRACE_STEP EXP, C06 -
- Conditions for start of trace recording STRING PowerOn
NBUP
- 2 ,, , , , , , , , , , , , , , ... - - 1/1 M
Description: The machine data is only intended for diagnostic use.
See TRACE_STARTTRACE_EVENT
For TRACE_STARTTRACE_EVENT BLOCK_CHANGE the string TRACE_STARTTRACE_STEP is
interpreted as a file name and block number!
For BSEVENTTYPE_SETALARM the string is interpreted as an alarm number.
The machine data can be additionally activated using the Cancel alarm key.
22704 TRACE_STOPTRACE_EVENT EXP, C06 -
- Conditions for stop of trace recording STRING PowerOn
NBUP
- - CLEARCANCELALAR
M_M,
CLEARCANCELALAR
M_M,
CLEARCANCELALAR
M_M, CLEA...
- - 1/1 M
Description: The machine data is only intended for diagnostics.
The recording of the diagnostic data ends when the event (TRACE_STOPTRACE_EVENT) has
occurred at the trace point (TRACE_STOPTRACE_TRACEPOINT) and in the correct step
(TRACE_STOPTRACE_STEP)!
After reaching the stop condition, the previously recorded diagnostic data is stored
in a file "NCSCTRyy.MPF" or for NCU-LINK in "NCxxTRyy.MPF" in the MPF directory.
The machine data is additionally activated using the Cancel alarm key.
22706 TRACE_STOPTRACE_STEP EXP, C06 -
- CommandSequenzStep with which the recording ends STRING PowerOn
NBUP
- 2 , , , , , , , , , , , , , , , ... - - 1/1 M
Description: The machine data is only intended for diagnostics.
The machine data can be additionally activated using the Cancel alarm key.
22708 TRACE_SCOPE_MASK EXP, C06 -
- Selects the contents of the trace file STRING PowerOn
NBUP
- - - - - 1/1 M
Description: The machine data is only intended for diagnostics purposes.
Specific trace contents are selected with the MD data.
The entry SETALARM records the alarm environment and the block change in the main run
is also logged by means of BLOCK_CHANGE.
The machine data is additionally activated using the Cancel alarm key.
Machine data
3.3 Channel-specific machine data
Parameter Manual
176 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
