22710 TRACE_VARIABLE_NAME - -
- Definition of trace data STRING PowerOn
NBUP
- 10 BL_NR, TR_POINT,
EV_TYPE, EV_SRC,
CS_ASTEP,, BL_NR,
TR_POINT, EV...
- - 1/1 M
Description: The machine data is only intended for diagnostic purposes.
The MD datum defines which data are recorded in the trace file.
22712 TRACE_VARIABLE_INDEX EXP, C06 -
- Index for trace recording data DWORD PowerOn
NBUP
- 10 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0,
0x0,...
0 0xFFFF 1/1 M
Description: The machine data is only intended for diagnostic use.
The MD data, together with TRACE_VARIABLE_NAME, determines which data are recorded in
the trace file.
It enables access to an array element.
E.g. use as an axis index when accessing axis data.
22714 MM_TRACE_DATA_FUNCTION EXP, C02, C06 -
- Activating diagnostics DWORD PowerOn
NBUP
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0xFFFFFF 1/1 M
Description: The machine data is only intended for diagnostic purposes.
Activating diagnostics
An internal ring buffer records important events.
After a trigger event, with the 'Cancel alarm' key set as default,
the ring buffer is briefly frozen, read, and converted into an ASCII file
in the part program directory. The file name for the 1st channel
is ncsctr01.mpf and for the 7th channel it is ncsctr07.mpf.
The data in the ring buffer is referred to as dynamic data in the following.
In addition to the trigger event, other up-to-date data is read from the
NCK and transferred to the ASCII file. These recordings do
NOT have a history and are referred to as static data in the following.
Bit no. Significance when bit is set
------------------------------------------------------------------
0 (LSB) Recording of dynamic data (see TRACE_VARIABLE_NAME)
1 Recording of block control static data
2 Recording of alarm data static data
3 Recording of process data static data
4 Recording of command sequence static data
5 Recording of tool management static data
6 Recording of the NCK version file. Static data
7 Recording of the statuses of the current block
Various statuses of the axes and the SPARPI. Static data
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 177
