8 Recording of various statuses of the channel. Static data
9 Error statuses in the NCK memory management are scanned during trace generation.
An error renames the trace file. Static data
Possible names and their meaning:
NCFIER.MPF Error in the file system
NCSLER.MPF Error during string creation
NCFIER.MPF Error on New/Delete
10 All block changes in the interpreter are recorded. Dynamic data.
11 Axial VDI signals are recorded. Dynamic data.
Only in conjunction with MD18794 $MN_MM_TRACE_VDI_SIGNAL
12 OEM traces are activated. Dynamic data.
13 Synchronized actions are recorded. Dynamic data.
NOTICE: Filled in applications with intensive use of
these trace points, other events are ignored!
That is why this bit should remain at 0 in these cases.
14 Reserved.
15 Recording of station commands. Dynamic data.
Note: Most important output of the NCK module NCSC!
16 Recording of gantry commands
17 Recording of changes in the drive's status
18 Recording of the processing of the Event-Queue and generation of command sequences
19 Recording of event destructor call
20 Recording of the dynamic limitations per block (only active when bit 0 is set).
21 Recording of the Look Ahead data (only active when bit 0 is set).
22 Recording of all Functions Config data.
Both a static part as well as a block-related part with the dynamic block data
are output at the time of trace generation.
22 Config data output (static)
23 Recording if computing time is given away in the preprocessing (only active when
bit 0 is set).
22910 WEIGHTING_FACTOR_FOR_SCALE EXP, C01, C11 -
- Input resolution for scaling factor BOOLEAN PowerOn
-
- - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 2/2 M
Description: Definition of the unit for the scaling factor P and for the axial scaling factors I,
J, K.
Meaning:
0 Scale factor in 0.001
1 Scale factor in 0.00001
Related to:
SD43120 $SA_DEFAULT_SCALE_FACTOR_AXIS,
SD42140 $SC_DEFAULT_SCALE_FACTOR_P
Machine data
3.3 Channel-specific machine data
Parameter Manual
178 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
