22930 EXTERN_PARALLEL_GEOAX EXP, C01, C11 -
- Assignment of a parallel channel axis to the geometry axis BYTE PowerOn
-
- 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 2/2 M
Description: Assignment table of the axes positioned parallel to the geometry axes.
This table can be used to assign channel axes positioned parallel to the geometry axes.
The parallel axes can then be activated as geometry axes in ISO mode using the G
functions of plane selection (G17 - G19) and the axis name of the parallel axis.
Prerequisite:
The channel axes used must be active. ( list position assigned in
AXCONF_MACHAX_USED ). Entering zero deactivates the corresponding parallel geometry
axis:
24020 FRAME_SUPPRESS_MODE C03 K2
- Positions for frame suppression DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x0000003 2/2 M
Description: Bit mask for configuring the positions for frame suppressions (SUPA, G153, G53).
The following rule applies:
Bit 0: Positions for display (OPI) without frame suppression
Bit 1: Position variables without frame suppression
24030 FRAME_ACS_SET C03 K2
- Adjustment of SZS coordinate system DWORD PowerOn
-
- - 1 0 1 1/1 M
Description: 0: SZS results from the Work transformed with $P_CYCFRAME and $P_PFRAME.
1: SZS results from the Work transformed with the $P_CYCFRAME.
24040 FRAME_ADAPT_MODE C03 K2
- Adaptation of active frames DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x0000007 1/1 M
Description: Bit mask for adapting the active frames or axis configuration
The following applies:
Bit 0:
Rotations in active frames that rotate coordinate axes for which there are no geometry
axes are deleted from the active frames.
Bit 1:
Shear angles in active frames are orthogonalized.
Bit 2:
Scalings of all geometry axes in the active frames are set to value 1.
Machine data
3.3 Channel-specific machine data
Parameter Manual
180 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
