24050 FRAME_SAA_MODE C03 -
- Saving and activating of data management frames DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x0000003 1/1 M
Description: Bit mask for saving and activating data management frames.
The following applies:
Bit 0:
Data management frames are only activated by programming the bit masks $P_CHBFRMASK,
$P_NCBFRMASK and $P_CHSFRMASK. G500..G599 only activate the relevant settable frame,
GFRAME0..GFRAME100
only activate
the corresponding grinding frame. The reset behavior
is independent of this.
Bit 1:
Data handling frames are not written implicitly by system functions such as TOROT,
PAROT, ext. work offset, transformations.
24080 USER_FRAME_POWERON_MASK N01 -
- Parameterize properties for settable frame DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x1 7/2 M
Description: Setting the following bits activates certain properties of the settable frame:
Bit 0 = 0: default behavior.
Bit 0 = 1: if MD20152 $MC_GCODE_RESET_MODE[7] = 1, the last active settable frame is
selected again according to G code group 8 after power up of the control.
24100 TRAFO_TYPE_1 C07 F2, TE4, M1, K1, W1
- Definition of transformation 1 in channel DWORD NEW CONF
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... - - 1/1 M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... - - 1/1 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... - - 1/1 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... - - 1/1 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... - - 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... - - 7/7 U
Description: This MD specifies the first available transformation in each channel.
The 4 low-value bits identify the specific transformation of a specific transformation
group. The transformation group is identified by a number starting with the 5th bit.
Meaning:
0 No transformation
ab 16
5-axis transformation with turnable tool
ab 32
5-axis transformation with turnable workpiece
ab 48
5-axis transformation with turnable tool and turnable workpiece
72
Generic 5-axis transformation. Type and kinematic data are determined by an
associated, orientable toolholder.
see:
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 181
