The 4 low-value bits have the following meaning for a 5-axis transformation:
0 axis sequence AB
1 axis sequence AC
2 axis sequence BA
3 axis sequence BC
4 axis sequence CA
5 axis sequence CB
8 Generic orientation transformation (3- 5 axes)
ab 256
TRANSMIT transformation
ab 512
TRACYL transformation
ab 1024
TRAANG transformation
2048
TRACLG: centerless transformation
ab 4096 bis 4098
OEM transformation
ab 8192
TRACON: cascaded transformations
Example:
A 5-axis transformation with turnable tool and axis sequence CA (i.e. C axis turns A
axis) has number 20 ( = 16 + 4 )
Notice:
Not all combinations of group numbers and axis sequence numbers are allowed. An error
message is output if a number for a non-existent transformation is entered.
Corresponds with:
MD24200 $MC_TRAFO_TYPE_2, MD24300 $MC_TRAFO_TYPE_3, ... MD24460 $MC_TRAFO_TYPE_8
References:
/FB/, F2, "5-Axis Transformation"
24110 TRAFO_AXES_IN_1 C07 F2, TE4, M1, K1, W1
- Axis assignment for the 1st transformation in the channel BYTE NEW CONF
-
808d-me42 4 0, 0, 0, 0 0 20 1/1 M
808d-me62 5 0, 0, 0, 0, 0 0 20 1/1 M
808d-te42 4 0, 0, 0, 0 0 20 1/1 M
808d-te62 4 0, 0, 0, 0, 0 0 20 1/1 M
808d-mte40 4 1, 2, 3, 4, 5, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,, ...
0 20 7/7 U
808d-mte60 20 1, 2, 3, 4, 5, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,, ...
0 20 7/7 U
Description: Axis assignment at input point of 1st transformation
The index input at the nth position states which axis is mapped internally from the
transformation to axis n.
Not relevant:
No transformation
Releated to:
Machine data
3.3 Channel-specific machine data
Parameter Manual
182 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
