MD24200 $MC_TRAFO_TYPE_2, MD24300 $MC_TRAFO_TYPE_3, ...
MD24460 $MC_TRAFO_TYPE_8
References:
/FB/, F2, "5-Axis Transformation"
24120 TRAFO_GEOAX_ASSIGN_TAB_1 C07 F2, TE4, TE4, M1, K1, W1
- Assignment of the geometry axes to channel axes for
transformation 1
BYTE NEW CONF
-
808d-me42 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-me62 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-te42 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-te62 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-mte40 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 7/7 U
808d-mte60 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 7/7 U
Description: This MD states the channel axes on which the axes of the cartesian coordinate system
are mapped for active transformation 1.
Not relevant:
No transformation
Related to:
MD20050 $MC_AXCONF_GEOAX_ASSIGN_TAB, if no transformation is active.
References:
/FB/, K2, "Coordinate Systems, Axis Types, Axis Configurations, Workpiece-Related
Actual Value System, External Work Offset"
24130 TRAFO_INCLUDES_TOOL_1 C07 -
- Tool handling with 1st active transformation BOOLEAN NEW CONF
-
808d-me42 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-me62 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-te42 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-te62 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 183
