Siemens SINUMERIK 808D ADVANCED Parameter Manual

808d-mte40 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 7/7 U
808d-mte60 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 7/7 U
Description: Indicates a basic offset of the tools zero for the 1st TRANSMIT transformation. The
offset is referenced to the geometry axes valid when TRANSMIT is active. The basic
offset is included with and without selection of the tool length compensation.
Programmed length corrections have an additive effect with respect to the basic tool.
The index i takes the values 0, 1, 2 for the 1st to 3rd geometry axes.
Related to:
MD24970 $MC_TRANSMIT_BASE_TOOL_2
24950 TRANSMIT_ROT_AX_OFFSET_2 C07 M1
degrees Offset of rotary axis for the 2nd TRANSMIT transformation DOUBLE NEW CONF
-
808d-me42 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 1/1 M
808d-me62 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 1/1 M
808d-te42 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 1/1 M
808d-te62 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 1/1 M
808d-mte40 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 7/7 U
808d-mte60 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 7/7 U
Description: Indicates the offset of the rotary axis for the second agreed TRANSMIT transformation
in degrees in relation to the neutral position while TRANSMIT is active.
Related to:
MD24900 $MC_TRANSMIT_ROT_AX_OFFSET_1
24955 TRANSMIT_ROT_AX_FRAME_2 C07 M1
- Rotary axis offset TRANSMIT 2 BYTE NEW CONF
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 7/7 U
Description: 0: axial rotary axis offset is not considered.
1: axial rotary axis offset is considered.
2: axial rotary axis offset is considered until SZS.
SZS frames include transformed rotations around the rotary axis.
Machine data
3.3 Channel-specific machine data
Parameter Manual
190 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
