808d-te42 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-te62 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-mte40 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 7/7 U
808d-mte60 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 7/7 U
Description: Indicates the sign with which the rotary axis is taken into account in the TRANSMIT
transformation for the first agreed TRANSMIT transformation for each channel.
Related to:
MD24960 $MC_TRANSMIT_ROT_SIGN_IS_PLUS_2
24911 TRANSMIT_POLE_SIDE_FIX_1 C07 M1
- Restriction of working range in front of / behind the pole, 1.
TRANSMIT
BYTE NEW CONF
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 7/7 U
Description: Restriction of the working area in front of/behind pole or no restriction, i.e.
traversal through the pole.
The assigned values have the following meanings:
1: Working area of linear axis for positions >=0,
(if tool length compensation parallel to linear axis equals 0)
2: Working area of linear axis for positions <=0,
(if tool length compensation parallel to linear axis equals 0)
0: No restriction of working area. Traversal through pole.
24920 TRANSMIT_BASE_TOOL_1 C07 M1
mm Vector of base tool for 1st TRANSMIT transformation DOUBLE NEW CONF
-
808d-me42 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
808d-me62 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
808d-te42 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
808d-te62 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 189
