Description: Indicates a basic offset of the tools zero for the 1st TRACYL transformation. The
offset is referenced
to the geometry axes valid when TRACYL is active. The basic offset
is included with and without selection of the tool length compensation. Programmed
length corrections have an additive effect with respect to the basic tool.
The index i takes the values 0, 1, 2 for the 1st to 3rd geometry axes.
Related to:
MD24870 $MC_TRACYL_BASE_TOOL_2
24900 TRANSMIT_ROT_AX_OFFSET_1 C07 M1
degrees Offset of rotary axis for the 1st TRANSMIT transformation DOUBLE NEW CONF
-
808d-me42 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 1/1 M
808d-me62 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 1/1 M
808d-te42 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 1/1 M
808d-te62 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 1/1 M
808d-mte40 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 7/7 U
808d-mte60 - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 7/7 U
Description: Indicates the offset of the rotary axis for the first agreed TRANSMIT transformation
in degrees in relation to the neutral position while TRANSMIT is active.
Related to:
MD24950 $MC_TRANSMIT_ROT_AX_OFFSET_2
24905 TRANSMIT_ROT_AX_FRAME_1 C07 M1, K2
- Rotary axis offset TRANSMIT 1 BYTE NEW CONF
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 7/7 U
Description: 0: axial rotary axis offset is not considered.
1: axial rotary axis offset is considered.
2: axial rotary axis offset is considered until SZS.
SZS frames include transformed rotations around the rotary axis.
24910 TRANSMIT_ROT_SIGN_IS_PLUS_1 C07 M1
- Sign of rotary axis for 1st TRANSMIT transformation BOOLEAN NEW CONF
-
808d-me42 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-me62 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
Machine data
3.3 Channel-specific machine data
Parameter Manual
188 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
