0: without groove side offset (i.e. TRACYL type 514 - equals 512)
1: with groove side offset (i.e. TRACYL type 514 - equals 513)
MD2.... $MC_TRAFO_TYPE_... = 514 can be used to decide, via the selection parameters,
whether
calculation
is
made with or without groove side offset. The parameter defines
the variable to be selected if no selection is made in the call parameters.
If MD24808 $MC_TRACYL_DEFAULT_MODE_1 = 1, it is sufficient to program TRACYL(30) in
the part program instead of TRACYL(30,1,1).
24810 TRACYL_ROT_SIGN_IS_PLUS_1 C07 M1
- Sign of rotary axis for 1st TRACYL transformation BOOLEAN NEW CONF
-
808d-me42 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-me62 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-te42 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-te62 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 1/1 M
808d-mte40 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 7/7 U
808d-mte60 - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE, TRUE...
0 - 7/7 U
Description: Indicates the sign with which the rotary axis is taken into account in the TRACYL
transformation for the first agreed TRACYL transformation.
Related to:
MD24860 $MC_TRACYL_ROT_SIGN_IS_PLUS_2
24820 TRACYL_BASE_TOOL_1 C07 M1
mm Vector of base tool for 1st TRACYL transformation DOUBLE NEW CONF
-
808d-me42 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
808d-me62 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
808d-te42 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
808d-te62 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
808d-mte40 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 7/7 U
808d-mte60 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 7/7 U
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 187
