808d-me62 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
808d-te42 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
808d-te62 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 1/1 M
808d-mte40 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 7/7 U
808d-mte60 3 0.0, 0.0 , 0.0, 0.0, 0.0 ,
0.0, 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0, ...
- - 7/7 U
Description: Indicates a basic offset of the tools zero for the 2nd TRANSMIT transformation. The
offset is referenced to the geometry axes valid when TRANSMIT is active. The basic
offset is included with and without selection of the tool length compensation.
Programmed length corrections have an additive effect with respect to the basic tool.
The index i takes the values 0, 1, 2 for the 1st to 3rd geometry axes.
Related to:
MD24920 $MC_TRANSMIT_BASE_TOOL_1
27100 ABSBLOCK_FUNCTION_MASK N01 K1, P1
- Parameterize basic blocks with absolute values DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x1 2/2 M
Description: Parameterization of the "basic blocks with absolute values" function
Bit 0 = 1 :
The position values of the transverse axis are always displayed as diameter values.
Transverse axes can be applied using MD20100 $MC_DIAMETER_AX_DEF or MD30460
$MA_BASE_FUNCTION_MASK, bit 2.
27400 OEM_CHAN_INFO A01, A11 -
- OEM version information STRING PowerOn
-
- 3 , , , , , , , , , , , , , , , , , , ,
, , , , ...
- - 2/2 M
Description: A version information freely available to the user
(is indicated in the version screen)
27800 TECHNOLOGY_MODE C09 A2, K1
- Mode of technology in channel BYTE NEW CONF
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 - ReadOnly S
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 - ReadOnly S
808d-te42 - 1 0 - ReadOnly S
808d-te62 - 1 0 - ReadOnly S
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 - 7/2 M
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 - 7/2 M
Description: This machine data can be used for stating the technology independently of the channel.
Machine data
3.3 Channel-specific machine data
Parameter Manual
192 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
