Description: Timers are provided as system variables under the function program runtime. While the
NCK-specific timers are
always activated (for time measurements since the last control
power on), the channel-specific timers have to be started via this machine data.
Meaning:
Bit 0 = 0
No measurement of total operating time for any part program
Bit 0 = 1
Measurement of total operating time is active for all part programs
($AC_OPERATING_TIME)
Bit 1 = 0
No measurement of current program runtime
Bit 1 = 1
Measurement of current program runtime is active ($AC_CYCLE_TIME)
Bit 2 = 0
No measurement of tool operating time
Bit 2 = 1
Measurement of tool operating time is active ($AC_CUTTING_TIME)
Bit 3
Reserved
Bits 4,5 only when bit 0, 1, 2 = 1:
Bit 4 = 0 No measurement with active dry run feed
Bit 4 = 1 Measurement also with active dry run feed
Bit 5 = 0 No measurement with program test
Bit 5 = 1 Measurement also with program test
Bit 6 only when Bit 1 = 1:
Bit 6 = 0
Delete $AC_CYCLE_TIME also with start by ASUB and PROG_EVENTs
Bit 6 = 1
$AC_CYCLE_TIME is not deleted on start by ASUB and PROG_EVENTs.
Bit 7 only when bit 2 = 1:
Bit 7 = 0 $AC_CUTTING_TIME counts only with active tool
Bit 7 = 1 $AC_CUTTING_TIME counts irrespective of tool
Bits 8 only when bit 1 = 1
Bit 8 = 0
$AC_CYCLE_TIME is not deleted on jumping to program start with GOTOS
Bit 8 = 1
$AC_CYCLE_TIME is deleted on jumping to program start with GOTOS.
Bit 9 only when bits 0, 1 = 1:
Bit 9 = 0
$AC_OPERATING_TIME, $AC_CYCLE_TIME: No measurement with override = 0.
Bit 9 = 1
$AC_OPERATING_TIME, $AC_CYCLE_TIME: Measurement also with override = 0.
Bits 10 to 31
Reserved
27880 PART_COUNTER C09 K1
- Activation of workpiece counter DWORD Reset
-
808d-me42 - 0x901 0 0x0FFFFFFF 1/1 M
Machine data
3.3 Channel-specific machine data
Parameter Manual
194 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
