STRING 1 byte per character, 200 characters per string are possible
AXIS 4 bytes
FRAME 400 bytes
28040 MM_LUD_VALUES_MEM C02 V2, K1
- Memory space for local user variables (DRAM) DWORD PowerOn
-
- - 125, 125, 125, 125,
125, 125, 125, 125...
125 32000 1/1 M
Description: This MD defines the amount of memory space available for LUD variables.
The maximum number of available LUDs is given by one of the limit values of MD28020
$MC_MM_NUM_LUD_NAMES_TOTAL or MD28040 $MC_MM_LUD_VALUES_MEM.
Related to:
MD28020 $MC_MM_NUM_LUD_NAMES_TOTAL
(number of local user variables (DRAM))
28050 MM_NUM_R_PARAM C02 K1
- Number of channel-specific R variables (SRAM) DWORD PowerOn
-
- - 300 0 32535 ReadOnly S
Description: Defines the number of R variables available in the channel. This machine data reserves
8 bytes of buffered user memory per R variable.
28070 MM_NUM_BLOCKS_IN_PREP EXP, C02 B1, K1
- Number of blocks for block preparation (DRAM) DWORD PowerOn
-
808d-me42 - 50 50 1000 0/0 S
808d-me62 - 80 50 1000 1/1 M
808d-te42 - 50 50 1000 0/0 S
808d-te62 - 50 50 1000 0/0 S
808d-mte40 - 50, 50, 50, 50, 50, 50,
50, 50...
20 1000 7/2 M
808d-mte60 - 50, 50, 50, 50, 50, 50,
50, 50...
20 1000 7/2 M
Description: Defines the number of NC blocks available for NC block preparation. This figure is
determined mainly by the system software and is used largely for optimization.
Approximately 10 Kbytes of dynamic memory is reserved per NC block.
Related to:
MD28060 $MC_MM_IPO_BUFFER_SIZE
(number of NC blocks with IPO buffer)
28081 MM_NUM_BASE_FRAMES C02 M5, K2
- Number of base frames (SRAM) DWORD PowerOn
-
- - 1, 1, 1, 1, 1, 1, 1, 1... 0 16 1/1 M
Description: Number of channel-specific base frames per channel.
The value corresponds to the number of field elements for the predefined field
$P_CHBFR[].
Buffered memory is reserved for this.
Machine data
3.3 Channel-specific machine data
Parameter Manual
198 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
