Siemens SINUMERIK 808D ADVANCED Parameter Manual

28082 MM_SYSTEM_FRAME_MASK C02 M5, K2, W1
- System frames (SRAM) DWORD PowerOn
-
808d-me42 - 0x7A1 0 0x00000FFF ReadOnly S
808d-me62 - 0x7A1 0 0x00000FFF ReadOnly S
808d-te42 - 0x7A1 0 0x00000FFF ReadOnly S
808d-te62 - 0x7A1 0 0x00000FFF ReadOnly S
808d-mte40 - 0x21, 0x21, 0x21,
0x21, 0x21, 0x21,
0x21, 0x21...
0 0x00000FFF 7/2 S
808d-mte60 - 0x21, 0x21, 0x21,
0x21, 0x21, 0x21,
0x21, 0x21...
0 0x00000FFF 7/2 S
Description: Bit mask for configuring channel-specific system frames included in the channel.
Bit 0: System frame for setting actual value and scratching
Bit 1: System frame for external work offset
Bit 2: System frame for TCARR aund PAROT
Bit 3: System frame for TOROT and TOFRAME
Bit 4: System frame for workpiece reference points
Bit 5: System frame for cycles
Bit 6: System frame for transformations
Bit 7: System frame $P_ISO1FR for ISO G51.1 Mirror
Bit 8: System frame $P_ISO2FR for ISO G68 2DROT
Bit 9: System frame $P_ISO3FR for ISO G68 3DROT
Bit 10: System frame $P_ISO4FR for ISO G51 Scale
Bit 11: System frame $P_RELFR for relative coordinate systems
28083 MM_SYSTEM_DATAFRAME_MASK C02 -
- System frames (SRAM) DWORD PowerOn
-
- - 0xF9F, 0xF9F, 0xF9F,
0xF9F, 0xF9F, 0xF9F,
0xF9F, 0xF9F...
0 0x00000FFF 1/1 S
Description: Bit mask for configuring channel-specific system frames in the data storage (SRAM).
Bit 0: System frame for setting actual value and scratching
Bit 1: System frame for external work offset
Bit 2: System frame for TCARR aund PAROT
Bit 3: System frame for TOROT and TOFRAME
Bit 4: System frame for workpiece reference points
Bit 5: System frame for cycles
Bit 6: System frame for transformations
Bit 7: System frame $P_ISO1FR for ISO G51.1 Mirror
Bit 8: System frame $P_ISO2FR for ISO G68 2DROT
Bit 9: System frame $P_ISO3FR for ISO G68 3DROT
Bit 10: System frame $P_ISO4FR for ISO G51 Scale
Bit 11: System frame $P_RELFR for relative coordinate systems
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 199
