28180 MM_MAX_TRACE_DATAPOINTS EXP, C02, C06 -
- Length of the trace data buffer DWORD PowerOn
NBUP
- - 100, 100, 100, 100,
100, 100, 100, 100...
0 20000 1/1 M
Description: MM_MAX_TRACE_DATAPOINTS defines the size of an internal data buffer which contains the
trace recordings.
28200 MM_NUM_PROTECT_AREA_CHAN C02, C06, C09 A3
- Number of channel-specific protection zones (SRAM) DWORD PowerOn
-
808d-me42 - 10 0 10 1/1 M
808d-me62 - 10 0 10 1/1 M
808d-te42 - 10 0 10 1/1 M
808d-te62 - 10 0 10 1/1 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 10 1/1 M
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 10 1/1 M
Description: This machine data defines how many channel-specific protection areas are set up.
Related to:
MD28210 $MC_MM_NUM_PROTECT_AREA_ACTIVE (number of simultaneously active protection
areas)
MD18190 $MN_MM_NUM_PROTECT_AREA_NCK (number of control-specific protection areas
(SRAM))
References:
/FB/, A3, "Axis/Contour Tunnel Monitoring, Protection Areas"
28210 MM_NUM_PROTECT_AREA_ACTIVE C11, C02, C06,
C09
A3
- Number of simultaneously active protection zones in one channel DWORD PowerOn
-
808d-me42 - 10 0 10 1/1 M
808d-me62 - 10 0 10 1/1 M
808d-te42 - 10 0 10 1/1 M
808d-te62 - 10 0 10 1/1 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 10 1/1 M
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 10 1/1 M
Description: This machine data defines the number of protection areas that may be activated
simultaneously for each channel.
It is not practical to enter a numerical value greater than MD18190
$MN_MM_NUM_PROTECT_AREA_NCK + MD28200 $MC_MM_NUM_PROTECT_AREA_CHAN.
Related to:
MD28200 $MC_MM_NUM_PROTECT_AREA_CHAN (Number of blocks for channel-specific
protection areas)
MD18190 $MN_MM_NUM_PROTECT_AREA_NCK (Number of control-specific protection areas
(SRAM))
References:
/FB1/ Function Manual Basic Functions; Axis Monitoring, Protection Areas (A3)
