Siemens SINUMERIK 808D ADVANCED Parameter Manual

n=5: Current write index relative to FIFO start
Related to:
MD28260 $MC_NUM_AC_FIFO
28264 LEN_AC_FIFO C01 2.3, 2.4, 6.1, M5
- Length of FIFO variables $AC_FIFO1-$AC_FIFO10 DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 32535 1/1 M
Description: Length of the FIFO variables $AC_FIFO1 to $AC_FIFO10.
All FIFO variables are the same length.
28266 MODE_AC_FIFO C01 2.3, 2.4, 6.1
- Mode of FIFO processing BYTE PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 - 1/1 M
Description: Mode of FIFO processing:
Bit 0 = 1:
The sum of all FIFO contents is updated at each write access.
Bit 0 = 0:
No summation
Related to:
MD28260 $MC_NUM_AC_FIFO
28274 MM_NUM_AC_SYSTEM_PARAM EXP, C02 -
- Number of $AC_SYSTEM_ PARAM for motion-synchronous
actions
DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 20000 1/1 M
Description: Number of $AC_SYSTEM_ PARAM parameters for motion-synchronous actions.
Depending on MD28255 $MC_MM_BUFFERED_AC_PARAM, DRAM or SRAM is required.
Reserved for SIEMENS applications.
28276 MM_NUM_AC_SYSTEM_MARKER EXP, C02 -
- Number of $AC_SYSTEM_MARKER for motion-synchronous
actions
DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 20000 1/1 M
Description: Number of $AC_SYSTEM_MARKER markers for motion-synchronous actions.
Depending on MD28257 $MC_MM_BUFFERED_AC_MARKER, DRAM or SRAM is required.
Reserved for SIEMENS applications.
28290 MM_SHAPED_TOOLS_ENABLE C01, C08, C02 -
- Enable tool radius compensation for contour tools BOOLEAN PowerOn
-
808d-me42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
Machine data
3.3 Channel-specific machine data
Parameter Manual
204 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
