Siemens SINUMERIK 808D ADVANCED Parameter Manual

808d-me62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-te42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-te62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-mte40 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/2 M
808d-mte60 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/2 M
Description: The function "Tool radius compensation for contour tools" is enabled with this tool.
28300 MM_PROTOC_USER_ACTIVE C02 -
- Activation of logging for a user BOOLEAN PowerOn
-
- 10 TRUE, TRUE, FALSE,
FALSE, FALSE,
TRUE,
TRUE, TRUE,
FALSE,, T...
0 - 1/1 M
Description: Activation of recording for a user.
The users 0 and 1, and 5 - 9 are reserved for system functions.
The users 2, 3 and 4 can be used by OEM.
28302 MM_PROTOC_NUM_ETP_STD_TYP C02 -
- Number of standard event types ETP DWORD PowerOn
-
- 10 28, 6, 0, 0, 0, 20, 20,
20, 0, 3, 28, 6, 0, 0, 0,
20, 20, 20, 0,...
28, 6, 0, 0, 0, 20,
20, 20...
59, 59, 59, 59,
59, 59, 59, 59...
1/1 M
Description: Number of standard event types required in the ETP OPI block.
28400 MM_ABSBLOCK EXP, C02 K1
- Activate basic blocks with absolute values DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 512 2/2 M
Description: Value:
0: Basic blocks with absolute values deactivated.
1: Basic blocks with absolute values activated;
A display buffer of the following size is created:
(MD28257 $MC_MM_BUFFERED_AC_MARKER + MD28070 $MC_MM_NUM_BLOCKS_IN_PREP) * 256 bytes
>= 128: Basic blocks with absolute values activated.
Machine data
3.3 Channel-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 205
