Siemens SINUMERIK 808D ADVANCED Parameter Manual

28402 MM_ABSBLOCK_BUFFER_CONF EXP, C02 K1
- Setting of upload buffer size DWORD PowerOn
-
- 2 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0...
0 32000 2/2 M
Description: Dimensioning the size of the upload buffer:
MD28402 $MC_MM_ABSBLOCK_BUFFER_CONF[0] : Number of blocks before the current block
MD28402 $MC_MM_ABSBLOCK_BUFFER_CONF[1] : Number of blocks after the current block
The machine data is tested for the following upper / lower limits during startup:
0 <= MD28402 $MC_MM_ABSBLOCK_BUFFER_CONF[0] <= 8
Alarm 4152 is issued when the limits are violated.
28520 MM_MAX_AXISPOLY_PER_BLOCK C02 B1
- Maximal number of axial polynomials per block DWORD PowerOn
-
808d-me42 - 1 1 15 0/0 S
808d-me62 - 3, 3, 3, 3, 3, 3, 3, 3... 1 15 1/1 M
808d-te42 - 1 1 15 0/0 S
808d-te62 - 1 1 15 0/0 S
808d-mte40 - 3, 3, 3, 3, 3, 3, 3, 3... 1 15 0/0 S
808d-mte60 - 3, 3, 3, 3, 3, 3, 3, 3... 1 15 0/0 S
Description: Maximum number of axis polynomials which can be contained in a block.
In the standard case, each block only contains one polynomial per axis, i.e. this data
can immediately be set to one.
Currently, more polynomials are only needed for the new ADIS function with G643.
In this case, this data must have a minimum value of three.
28530 MM_PATH_VELO_SEGMENTS C02 A2, B1
- Number of memory elements for path velocity limitation DWORD PowerOn
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 100 0/0 S
808d-me62 - 5 0 100 1/1 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 100 0/0 S
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 100 0/0 S
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 100 0/0 S
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 100 0/0 S
Description: Number of memory elements available for limiting the path velocity and changing it in
the block.
0 : Each block is limited by a maximum path velocity.
> 0 : If required, a profile of the permissible path velocity
; and its modification options is generated and monitored
; in the block.
; This results in a smoother axis velocity progression and
; a shorter travel time.
; MD28530 $MC_MM_PATH_VELO_SEGMENTS defines the average
; number of segments available in the block.
; The necessary setting essentially depends
; on the requirements.
Machine data
3.3 Channel-specific machine data
Parameter Manual
206 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
