Description: Defines the size of the modulo range. Default positions are accepted and displayed
within this range. Useful modulo ranges are n * 360 degrees with integer n. Other
settings are equally possible in principle. Attention should be paid to having a
useful relationship between the positions in the NC and the mechanics (ambiguity).
Velocity definitions are not affected by settings in this MD.
30340 MODULO_RANGE_START EXP, A01 R1, R2
degrees Modulo range start position DOUBLE Reset
CTEQ
- - 0.0 - - 1/1
Description: Defines the start position for the modulo range.
Example:
Start = 0 degree -> modulo range 0 <->360 degrees
Start = 180 degrees -> modulo range 180 <->540 degrees
Start = -180 degrees -> modulo range -180 <->180 degrees
30350 SIMU_AX_VDI_OUTPUT A01, A06 A2, G2, Z1
- Axis signals output for simulation axes BOOLEAN PowerOn
CTEQ
- - FALSE 0 - 1/1
Description: The machine data defines whether axis-specific interface signals are output to the PLC
while an axis is being simulated.
1: The axis-specific NC/PLC interface signals for a simulated axis are output to the
PLC.
This means that the user PLC program can be tested without the drives having to be
available.
0: The axis-specific NC/PLC interface signals for a simulated axis are not output to
the PLC.
All axis-specific NC/PLC interface signals are set to "0".
Not relevant for:
MD30130 $MA_CTRLOUT_TYPE (setpoint output type) = 1
30450 IS_CONCURRENT_POS_AX EXP, A01 G1
- Default for reset: neutral/channel axis BOOLEAN Reset
CTEQ
808d-me42 - FALSE 0 - 0/0
808d-me62 - FALSE 0 - 0/0
808d-te42 - FALSE 0 - 0/0
808d-te62 - FALSE 0 - 0/0
808d-mte40 - FALSE 0 - 7/2
808d-mte60 - FALSE 0 - 7/2
Description: For SW4.3:
If FALSE: On RESET, a neutral axis is reassigned to the NC program.
If TRUE: On RESET, a neutral axis remains in the neutral axis state and an axis
assigned to the NC program becomes a neutral axis
30455 MISC_FUNCTION_MASK A06, A10 R2, S3, R1
- Axis functions DWORD Reset
CTEQ
- - 0x00 0 0x7FFF 1/1
Description: Bit 0 = 0:
Machine data
3.4 Axis-specific machine data
Parameter Manual
216 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
