808d-mte40 1 2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048...
1 - 2/2
808d-mte60 1 2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048...
1 - 2/2
Description: For rotary measuring system only:
The number of encoder lines per encoder revolution must be entered in this MD.
Index [n] of the machine data has the following coding:
[encoder no.]: 0 or 1
31030 LEADSCREW_PITCH A02, A11 G2, A3
mm Pitch of leadscrew DOUBLE PowerOn
-
- - 10.0 0.0 - 2/2
Description: The ball screw lead must be entered in the MD (see data sheet: mm/rev or inch/rev).
Special meaning for hydraulic linear drives:
If a hydraulic linear drive (HLA) is configured as rotary axis, it must be specified
in this MD, which drive feedrate in mm corresponds to a programmed revolution (360
degrees).
31040 ENC_IS_DIRECT A02, A11 G2, S1
- Direct measuring system (no compilation to load position) BOOLEAN PowerOn
-
- 1 FALSE, FALSE 0 - 2/2
Description: MD = 1:
Encoder for actual position value sensing is attached directly to the machine (without
an intermediate gear unit).
MD = 0:
Encoder for actual position value sensing is attached to the motor (MD31060
$MA_DRIVE_AX_RATIO_NUMERA and MD31050 $MA_DRIVE_AX_RATIO_DENOM are included in the
encoder valuation).
The index[n] of the machine data has the following coding:
[encoder no.]: 0 or 1
Special cases:
An incorrect entry may result in an incorrect encoder resolution, as, for example, the
gear ratios would be calculated incorrectly.
31050 DRIVE_AX_RATIO_DENOM A02, A11 A2, A3, G2, S1, V1
- Denominator load gearbox DWORD PowerOn
-
- 6 1, 1, 1, 1, 1, 1 1 2147000000 2/2
Description: The load gearbox denominator is entered in this MD.
The index [n] of the machine data has the following coding:
[control parameter set no.]: 0-5
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 223
