31060 DRIVE_AX_RATIO_NUMERA A02, A11 A2, A3, G2, S1, V1
- Numerator load gearbox DWORD PowerOn
-
- 6 1, 1, 1, 1, 1, 1 -2147000000 2147000000 2/2
Description: The load gearbox numerator is entered in this MD.
The index [n] of the machine data has the following coding:
[control parameter set no.]: 0-5
31070 DRIVE_ENC_RATIO_DENOM A02, A11 A3, G2, S1
- Denominator measuring gearbox DWORD PowerOn
-
- 1 1, 1 1 2147000000 2/2
Description: The measuring gearbox denominator is entered in this MD.
The index [n] of the machine data has the following coding:
[encoder no.]: 0 or 1
31080 DRIVE_ENC_RATIO_NUMERA A02, A11 A3, G2, S1
- Numerator measuring gearbox DWORD PowerOn
-
- 1 1, 1 1 2147000000 2/2
Description: The measuring gearbox numerator is entered in this MD.
The index [n] of the machine data has the following coding:
[encoder no.]: 0 or 1
31090 JOG_INCR_WEIGHT A01, A12 H1, G2
mm, degrees Evaluation of an increment with INC/handwheel DOUBLE Reset
CTEQ
- 2 0.001, 0.00254 - - 2/2
Description: The value entered in this MD defines the path of an increment which applies when an
axis is traversed with the JOG keys in incremental mode or with the handwheel.
The path traveled by the axis on each increment each time the traversing key is pressed
or for each handwheel detent position is defined by the following parameters:
● MD31090 $MA_JOG_INCR_WEIGHT
(Weighting of an increment of a machine axis for INC/handwheel)
● Selected increment size (INC1, ..., INCvar)
The possible increment stages are defined globally for all axes in MD11330
$MN_JOG_INCR_SIZE_TAB [n] and in SD41010 $SN_JOG_VAR_INCR_SIZE.
Entering a negative value reverses the direction of evaluation of the traverse keys
and the handwheel rotation.
Related to:
MD11330 $MN_JOG_INCR_SIZE_TAB
SD41010 $SN_JOG_VAR_INCR_SIZE
31092 JOG_INCR_WEIGHT_TRAFO A01, A12 H1, G2
mm, degrees Evaluation of an increment for INC/handwheel for active
transformation
DOUBLE Reset
CTEQ
- 2 0.0, 0.0 - - 2/2
Machine data
3.4 Axis-specific machine data
Parameter Manual
224 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
