Description: The input value is used to define the distance of an increment which, when traversing
an axis during
active transformation using the JOG keys, is valid for the incremental
dimension or via handwheel.
The distance, through which the axis traverses when executing the incremental
dimension with transformation active, depending on the traversing key actuated or
handwheel grid position, is defined by the following parameters:
● MD31092 $MA_JOG_INCR_WEIGHT_TRAFO
(Evaluating an increment of a machine axis for INC/handwheel)
● selected increment size (INC1, ..., INCvar)
The possible increment steps are globally defined for all axes in MD11330
$MN_JOG_INCR_SIZE_TAB [n] or in SD41010 $SN_JOG_VAR_INCR_SIZE.
Entering a negative value reverses the direction evaluation of the traversing keys and/
or the handwheel direction of rotation.
The set value is only effective, if this is > 0 ist. For values of zero, then MD31090
$MA_JOG_INCR_WEIGHT is effective
Corresponds with:
MD11330 $MN_JOG_INCR_SIZE_TAB
MD31090 $MA_JOG_INCR_WEIGHT
SD41010 $SN_JOG_VAR_INCR_SIZE
31100 BERO_CYCLE A02, EXP, A01 G2
- Steps for rotation monitoring DWORD PowerOn
CTEQ
808d-me42 1 10000, 10000, 10000, 0 0 10000000 1/1
808d-me62 1 2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000...
10 10000000 0/0
808d-te42 1 10000, 10000, 10000, 0 0 10000000 1/1
808d-te62 1 2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000...
10 10000000 0/0
808d-mte40 1 2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000...
10 10000000 1/1
808d-mte60 1 2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000...
10 10000000 0/0
Description: Repetition cycle from BERO in steps
31110 BERO_EDGE_TOL A02, A01, A12 H1, G2
- Step tolerance for rotation monitoring DWORD NEW CONF
CTEQ
808d-me42 1 4000, 4000, 4000, 0 0 10000000 1/1
808d-me62 1 50, 50, 50, 50, 50, 50,
50, 50, 50, 50, 50, 50,
50, 50, 50, 50...
10 10000000 0/0
808d-te42 1 4000, 4000, 4000, 0 0 10000000 1/1
808d-te62 1 50, 50, 50, 50, 50, 50,
50, 50, 50, 50, 50, 50,
50, 50, 50, 50...
10 10000000 0/0
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 225
