Siemens SINUMERIK 808D ADVANCED Parameter Manual

808d-mte40 1 50, 50, 50, 50, 50, 50,
50, 50, 50, 50, 50, 50,
50, 50, 50, 50...
10 10000000 1/1
808d-mte60 1 50, 50, 50, 50, 50, 50,
50, 50, 50, 50, 50, 50,
50, 50, 50, 50...
10 10000000 0/0
Description: BERO edge tolerance in steps
31122 BERO_DELAY_TIME_PLUS A02, A06 S1, R1
s BERO delay time Plus DOUBLE NEW CONF
-
- 1 0.000110, 0.000110 0.0 - 2/2
Description: This machine data in combination with the setting in MD34200 $MA_ENC_REFP_MODE
(referencing mode) =
7 causes a signal runtime compensation in the positive direction
of movement at a position determined by a BERO (zero mark).
The typical total delay time of the BERO message path for overtravel in the positive
direction of movement is entered.
This time includes:
● the BERO edge delay time
● the time for digitizing the signal
● the time for processing the measured value, etc.
The periods of time depend on the hardware used. The default value is typical for
SIEMENS products. Adjustment by the customer is only required in exceptional cases.
Input of the minimum value "0.0" deactivates the compensation (only active in
combination with MD34200 $MA_ENC_REFP_MODE = 7).
The machine data is available for all encoders.
Related to:
MD34200 $MA_ENC_REFP_MODE (referencing mode)
MD34040 $MA_REFP_VELO_SEARCH_MARKER[n]
(reference point creep velocity [Enc. no.])
31123 BERO_DELAY_TIME_MINUS A02, A06 S1, R1
s BERO delay time minus DOUBLE NEW CONF
-
- 1 0.000078, 0.000078 0.0 - 2/2
Description: This machine data in combination with the setting in MD34200 $MA_ENC_REFP_MODE
(referencing
mode)
=
7 causes a signal runtime compensation in the negative direction
of movement at a position determined by a BERO (zero mark).
The typical total delay time of the BERO message path for overtravel in the negative
direction of movement is entered.
The time includes:
● the BERO edge delay time
● the time for digitizing the signal
● the time for processing the measured value, etc.
The periods of time depend on the hardware used. The default value is typical for
SIEMENS products. Adjustment by the customer is only required in exceptional cases.
Input of the minimum value "0.0" deactivates the compensation (only active in
combination with MD34200 $MA_ENC_REFP_MODE = 7).
The machine data is available for all encoders.
Related to:
MD34200 $MA_ENC_REFP_MODE (referencing mode)
MD34040 $MA_REFP_VELO_SEARCH_MARKER[n]
Machine data
3.4 Axis-specific machine data
Parameter Manual
226 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
