Siemens SINUMERIK 808D ADVANCED Parameter Manual

(creep velocity [Enc. no.])
31600 TRACE_VDI_AX EXP, N06 -
- Trace-specification for axial VDI signals BOOLEAN PowerOn
NBUP
- - FALSE 0 - 1/1
Description: This machine data determines whether the axial VDI signals for this axis are recorded
in the NCSC trace (according to MD18794 $MN_MM_TRACE_VDI_SIGNAL).
32000 MAX_AX_VELO A11, A04 M3, TE1, TE3, W6, Z3, H1, K3,
M1, P2, A3,
B2, G2, H2, S1, V1,
W1
mm/min, rev/min Maximum axis velocity DOUBLE NEW CONF
CTEQ
808d-me42 - 10000., 10000.,
10000., 36000.
(1e-9/ 1e-9) (1.e300/ 1.e300) 2/2
808d-me62 - 10000., 10000.,
10000., 36000., 36000.
(1e-9/ 1e-9) (1.e300/ 1.e300) 2/2
808d-te42 - 10000., 10000.,
10000., 36000.
(1e-9/ 1e-9) (1.e300/ 1.e300) 2/2
808d-te62 - 10000., 10000.,
10000., 36000.,
36000., 36000.
(1e-9/ 1e-9) (1.e300/ 1.e300) 2/2
808d-mte40 - (10000./3000),
(10000./3000),
(10000./3000),
(10000./3000), (100...
(1e-9/ 1e-9) (1.e300/ 1.e300) 2/2
808d-mte60 - (10000./3000),
(10000./3000),
(10000./3000),
(10000./3000), (100...
(1e-9/ 1e-9) (1.e300/ 1.e300) 2/2
Description: Maximum velocity at which the axis can permanently travel. The value limits both the
positive and the
negative axis velocity. The axis traverses at this velocity, if rapid
traverse has been programmed.
Depending on the MD30300 $MA_IS_ROT_AX, the maximum rotary or linear axis velocity has
to be entered.
In the machine data, the dynamic behavior of the machine and drive and the limit
frequency of the actual value acquisition must be taken into account.
32010 JOG_VELO_RAPID A11, A04 H1
mm/min, rev/min Rapid traverse in jog mode DOUBLE Reset
CTEQ
808d-me42 - 10000., 10000.,
10000., 36000.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-me62 - 10000., 10000.,
10000., 36000., 36000.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te42 - 10000., 10000.,
10000., 36000.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te62 - 10000., 10000.,
10000., 36000.,
36000., 36000.
(0./ 0.) (1.e300/ 1.e300) 2/2
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 227
