808d-mte40 - (10000./100),
(10000./100),
(10000./100),
(10000./100),
(10000./...
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-mte60 - (10000./100),
(10000./100),
(10000./100),
(10000./100),
(10000./...
(0./ 0.) (1.e300/ 1.e300) 2/2
Description: The axis velocity entered applies when the rapid traverse override key is pressed in
JOG mode and when the axial feedrate override is set to 100%.
The value entered must not exceed the maximum permissible axis velocity (MD32000
$MA_MAX_AX_VELO).
This machine data is not used for the programmed rapid traverse G0.
MD irrelevant to:
Operating modes AUTOMATIC and MDI
Related to:
MD32000 $MA_MAX_AX_VELO (maximum axis velocity)
MD32040 $MA_JOG_REV_VELO_RAPID
(revolutional feedrate for JOG with rapid traverse override)
NC/PLC interface signal DB3200 DBX1000.5,1004.5,1008.5 (Rapid traverse override)
NC/PLC interface signal DB3200 DBX4 (Feedrate override A-H)
32020 JOG_VELO A11, A04 H1
mm/min, rev/min Jog axis velocity DOUBLE Reset
CTEQ
808d-me42 - 2000., 2000., 2000.,
36000.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-me62 - 2000., 2000., 2000.,
36000., 36000.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te42 - 2000., 2000., 2000.,
36000.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te62 - 2000., 2000., 2000.,
36000., 36000., 36000.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-mte40 - (2000./30), (2000./30),
(2000./30), (2000./30),
(2000./30), (200...
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-mte60 - (2000./30), (2000./30),
(2000./30), (2000./30),
(2000./30), (200...
(0./ 0.) (1.e300/ 1.e300) 2/2
Description: The velocity entered applies to traversing in JOG mode when the axial feedrate
override switch position is 100%.
This velocity is only used when general SD41110 $SN_JOG_SET_VELO = 0 for linear axes,
and linear feedrate is selected (SD41100 $SN_JOG_REV_IS_ACTIVE = 0) or SD41130
$SN_JOG_ROT_AX_SET_VELO = 0 for rotary axes.
If this is the case, the axis velocity is active for
● continuous jogging
● incremental jogging (INC1, ... INCvar)
● handwheel jogging
The value entered must not exceed the maximum permissible axis velocity (MD32000
$MA_MAX_AX_VELO).
If DRF is active, the axis velocity for JOG must be reduced with MD32090
$MA_HANDWH_VELO_OVERLAY_FACTOR.
Machine data
3.4 Axis-specific machine data
Parameter Manual
228 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
