Siemens SINUMERIK 808D ADVANCED Parameter Manual

Spindles in JOG mode:
This machine data can also be used to define the JOG mode speed for specific spindles
(if SD41200 $SN_JOG_SPIND_SET_VELO = 0). However, the speed can be modified with the
spindle override switch.
Related to:
MD32000 $MA_MAX_AX_VELO
(maximum axis velocity)
MD32050 $MA_JOG_REV_VELO
(revolutional feedrate for JOG)
MD32090 $MA_HANDWH_VELO_OVERLAY_FACTOR
(ratio of JOG velocity to handwheel velocity (DRF))
SD41110 $SN_JOG_SET_VELO
(JOG velocity for G94)
SD41130 $SN_JOG_ROT_AX_SET_VELO
(JOG velocity for rotary axes)
NC/PLC interface signal DB3200 DBX4 (Feedrate override A-H)
32040 JOG_REV_VELO_RAPID A11, A04 H1, P2, R2, T1, V1, Z1
mm/rev Revolutional feedrate in JOG with rapid traverse override DOUBLE Reset
CTEQ
808d-me42 - 2.5, 2.5, 2.5, 1.0 0.0 - 1/1
808d-me62 - 2.5, 2.5, 2.5, 1.0, 1.0 0.0 - 1/1
808d-te42 - 2.5, 2.5, 2.5, 1.0 0.0 - 1/1
808d-te62 - 2.5, 2.5, 2.5, 1.0, 1.0,
1.0
0.0 - 1/1
808d-mte40 - 2.5, 2.5, 2.5, 2.5, 2.5,
2.5, 2.5, 2.5...
0.0 - 1/1
808d-mte60 - 2.5, 2.5, 2.5, 2.5, 2.5,
2.5, 2.5, 2.5...
0.0 - 1/1
Description: The value entered defines the revolutional feedrate of the axis in JOG mode with rapid
traverse override in
relation to the revolutions of the master spindle. This feedrate
is active when SD41100 $SN_JOG_REV_IS_ACTIVE = 1. (Revolutional feedrate active with
JOG)
MD irrelevant for:
SD41100 $SN_JOG_REV_IS_ACTIVE = "0"
Related to:
SD41100 $SN_JOG_REV_IS_ACTIVE (revolutional feedrate with JOG active)
MD32050 $MA_JOG_REV_VELO (revolutional feedrate with JOG)
32050 JOG_REV_VELO A11, A04 H1, P2, R2, T1, V1, Z1
mm/rev Revolutional feedrate in JOG DOUBLE Reset
CTEQ
808d-me42 - 0.5, 0.5, 0.5, 1.0 0.0 - 1/1
808d-me62 - 0.5, 0.5, 0.5, 1.0, 1.0 0.0 - 1/1
808d-te42 - 0.5, 0.5, 0.5, 1.0 0.0 - 1/1
808d-te62 - 0.5, 0.5, 0.5, 1.0, 1.0,
1.0
0.0 - 1/1
808d-mte40 - 0.5, 0.5, 0.5, 0.5, 0.5,
0.5, 0.5, 0.5...
0.0 - 1/1
808d-mte60 - 0.5, 0.5, 0.5, 0.5, 0.5,
0.5, 0.5, 0.5...
0.0 - 1/1
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 229
