Siemens SINUMERIK 808D ADVANCED Parameter Manual

Description: The value entered defines the revolutional feedrate of the axis in JOG mode in relation
to the revolutions of the master spindle.
This feedrate is active when SD41100 $SN_JOG_REV_IS_ACTIVE= 1 (revolutional feedrate
active with JOG).
MD irrelevant for:
Linear feedrate; i.e. SD41100 $SN_JOG_REV_IS_ACTIVE = 0
Related to:
SD41100 $SN_JOG_REV_IS_ACTIVE
(revolutional feedrate for JOG active)
MD32040 $MA_JOG_REV_VELO_RAPID
(JOG revolutional feedrate with rapid traverse override)
32060 POS_AX_VELO A12, A04 H1, P2, K1, V1, 2.4, 6.2
mm/min, rev/min Initial setting for positioning axis velocity DOUBLE Reset
CTEQ
808d-me42 - 10000., 10000.,
10000., 36000.
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-me62 - 10000., 10000.,
10000., 36000., 36000.
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-te42 - 10000., 10000.,
10000., 36000.
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-te62 - 10000., 10000.,
10000., 36000.,
36000., 36000.
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-mte40 - (10000./30),
(10000./30),
(10000./30),
(10000./30),
(10000./30),...
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-mte60 - (10000./30),
(10000./30),
(10000./30),
(10000./30),
(10000./30),...
(0./ 0.) (1.e300/ 1.e300) 1/1
Description: If a positioning axis is programmed in the part program without specifying the axis-
specific feedrate, the feedrate entered in MD32060 $MA_POS_AX_VELO is automatically
used for this axis. The feedrate in MD32060 $MA_POS_AX_VELO applies until an axis-
specific feedrate is programmed in the part program for this positioning axis.
MD irrelevant for:
MD32060 $MA_POS_AX_VELO is irrelevant for all axis types other than positioning axis.
Special cases:
If a ZERO velocity is entered in MD32060 $MA_POS_AX_VELO, the positioning axis does
not traverse if it is programmed without feed. If a velocity is entered in MD32060
$MA_POS_AX_VELO that is higher than the maximum velocity of the axis (MD32000
$MA_MAX_AX_VELO), the velocity is automatically restricted to the maximum rate.
32080 HANDWH_MAX_INCR_SIZE A05, A10 H1
mm, degrees Limitation of selected increment DOUBLE Reset
CTEQ
- - 0.0 0.0 - 1/1
Description: > 0: Limitation of size of selected increment MD11330 $MN_JOG_INCR_SIZE <Increment/
VDI signal>Ü or SD41010 $SN_JOG_VAR_INCR_SIZE for the associated machine axis
0: No limitation
Machine data
3.4 Axis-specific machine data
Parameter Manual
230 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
