32082 HANDWH_MAX_INCR_VELO_SIZE A05, A10, A04 -
mm/min, rev/min Limitation for velocity override DOUBLE Reset
CTEQ
808d-me42 - 500., 500., 500., 1800. (0./ 0.) (1.e300/ 1.e300) 1/1
808d-me62 - 500., 500., 500., 1800.,
1800.
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-te42 - 500., 500., 500., 1800. (0./ 0.) (1.e300/ 1.e300) 1/1
808d-te62 - 500., 500., 500., 1800.,
1800., 1800.
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-mte40 - (500.0/1.0),
(500.0/1.0),
(500.0/1.0),
(500.0/1.0),
(500.0/1.0),...
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-mte60 - (500.0/1.0),
(500.0/1.0),
(500.0/1.0),
(500.0/1.0),
(500.0/1.0),...
(0./ 0.) (1.e300/ 1.e300) 1/1
Description: For the velocity override of positioning axes:
>0: Limitation of size of selected increment $MN_JOG_INCR_SIZEL<Increment/VDI
signal> 0 or SD41010 $SN_JOG_VAR_INCR_SIZE for the associated machine axis
0: No limitation
32084 HANDWH_STOP_COND EXP, A10 H1
- Handwheel travel behavior DWORD Reset
CTEQ
- - 0x10FF 0 0x17FF 1/1
Description: Definition of the response of the handwheel travel to axis-specific VDI interface
signals or the CP-SW limit stop or a stop from an OEM application:
Bit = 0:
Interruption or collection of the distances preset via the handwheel.
Bit = 1:
Cancelation of the traversing motion or no collection.
Bit assignment:
Bit 0: feedrate override
Bit 1: spindle speed override
Bit 2: feedrate stop/spindle stop or CP-SW limit stop or stop from an OEM
application
Bit 3: clamping procedure running (= 0 no effect)
Bit 4: servo enable
Bit 5: pulse enable
For machine axis:
Bit 6 = 0
For handwheel travel, the maximum velocity at which the relevant machine axis can be
traversed is the feedrate set in MD32020 $MA_JOG_VELO.
Bit 6 = 1
For handwheel travel, the maximum velocity at which the relevant machine axis can be
traversed is the feedrate set in MD32000 $MA_MAX_AX_VELO.
Bit 7 = 0
The override is active in handwheel travel.
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 231
