32710 CEC_ENABLE A09 K3
- Enable of sag compensation BOOLEAN NEW CONF
-
808d-me42 - FALSE 0 - 1/1
808d-me62 - FALSE 0 - 1/1
808d-te42 - FALSE 0 - 1/1
808d-te62 - FALSE 0 - 1/1
808d-mte40 - FALSE 0 - 7/2
808d-mte60 - FALSE 0 - 7/2
Description: 1: Sag compensation is enabled for this axis.
Inter-axis machine geometry errors (e.g. sag and angularity errors) can be compensated
with sag compensation.
The function is not activated until the following conditions have been fulfilled:
● The "Interpolatory compensation" option is set
● The associated compensation tables have been loaded into the NC user memory and
enabled (SD41300 $SN_CEC_TABLE_ENABLE[t] = 1)
● The relevant position measuring system is referenced (NC/PLC interface signal
DB390x DBX0.4 / .5 = 1 (Referenced/synchronized 1 or 2)):
0: Sag compensation is not enabled for the compensation axis.
Related to:
MD18342 $MN_MM_CEC_MAX_POINTS[t]
Number of interpolation points for sag compensation
SD41300 $SN_CEC_TABLE_ENABLE[t]
Enable evaluation of sag compensation table t
NC/PLC interface signal DB390x DBX0.4 / .5
(referenced/synchronized 1 or 2)
32711 CEC_SCALING_SYSTEM_METRIC A09 K3, G2
- Measuring system of sag compensation BOOLEAN NEW CONF
-
808d-me42 - TRUE 0 - 1/1
808d-me62 - TRUE 0 - 1/1
808d-te42 - TRUE 0 - 1/1
808d-te62 - TRUE 0 - 1/1
808d-mte40 - TRUE 0 - 7/2
808d-mte60 - TRUE 0 - 7/2
Description: Compensation data exist in:
0: inch system
1: metric system
32720 CEC_MAX_SUM A09 K3
mm, degrees Maximum compensation value for sag compensation DOUBLE NEW CONF
-
808d-me42 - - 0 1.0 1/1
808d-me62 - - 0 1.0 1/1
808d-te42 - - 0 1.0 1/1
808d-te62 - - 0 1.0 1/1
Machine data
3.4 Axis-specific machine data
Parameter Manual
250 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
