34020 REFP_VELO_SEARCH_CAM A03, A11, A04 G1, R1
mm/min, rev/min Reference point approach velocity DOUBLE Reset
-
808d-me42 - 5000., 5000., 5000.,
720.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-me62 - 5000., 5000., 5000.,
720., 720.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te42 - 5000., 5000., 5000.,
720.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te62 - 5000., 5000., 5000.,
720., 720., 720.
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-mte40 - (5000.0/100.0),
(5000.0/100.0),
(5000.0/100.0),
(5000.0/100.0), ...
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-mte60 - (5000.0/100.0),
(5000.0/100.0),
(5000.0/100.0),
(5000.0/100.0), ...
(0./ 0.) (1.e300/ 1.e300) 2/2
Description: The reference point approach velocity is the velocity at which the machine axis
travels in the direction of the reference cam after the traversing key has been pressed
(phase 1). This value should be set at a magnitude large enough for the axis to be
stopped to 0 before it reaches a hardware limit switch.
MD irrelevant for:
Linear measuring systems with distance-coded reference marks
34030 REFP_MAX_CAM_DIST A03, A11 G1, R1
mm, degrees Maximum distance to reference cam DOUBLE Reset
-
- - 10000.0 0.0 - 2/2
Description: If the machine axis travels a maximum distance defined in MD34030
$MA_REFP_MAX_CAM_DIST from the starting position in the direction of the reference
cam, without reaching the reference cam (NC/PLC interface signal DB380x DBX1000.7
(Reference point approach
delay) is reset), the axis stops and alarm 20000 "Reference
cam not reached" is output.
Irrelevant to:
Linear measuring systems with distance-coded reference marks
34040 REFP_VELO_SEARCH_MARKER A03, A11, A04 G1, R1, S1
mm/min, rev/min Creep velocity DOUBLE Reset
-
808d-me42 1 300.00, 300.00,
300.00, 300.00,
300.00, 300.00,
720.00, 720.00
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-me62 1 300.00, 300.00,
300.00, 300.00,
300.00, 300.00,
720.00, 720.00, ...
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te42 1 300.00, 300.00,
300.00, 300.00,
300.00, 300.00,
720.00, 720.00
(0./ 0.) (1.e300/ 1.e300) 2/2
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 257
