222 USER_CLASS_PLC_ACCESS - -
- PLC project protection level BYTE Immediately
-
- 0 7 0 7 2/2 M
Description: PLC project protection level
223 USER_CLASS_WRITE_PWA - -
- Protected work area protection level BYTE Immediately
-
- 0 7 0 7 3/2 M
Description: Protected work area protection level
247 V24_PG_PC_BAUD - -
- PG: baud rate (300, 600, 1200, 2400, 4800, 9600, 19200, 38400) BYTE Immediately
-
- 0 7 5 9 3/3 U
Description: PG: baud rate (300, 600, 1200, 2400, 4800, 9600, 19200, 38400)
280 V24_PPI_ADDR_PLC - -
- PLC station address BYTE PowerOn
-
- - 2 0 126 3/3 U
Description: PLC station address
281 V24_PPI_ADDR_NCK - -
- NCK station address BYTE PowerOn
-
- - 3 0 126 3/3 U
Description: NCK station address
289 CTM_SIMULATION_TIME_NEW_POS - -
- Simulation of actual value update rate BOOLEAN Immediately
-
- 0 100 0 4000 4/3 U
Description: Use this MD to define the time intervals in which the simulation graphic is updated on
the current machine tool machining.
Value = 0 means no update
290 CTM_POS_COORDINATE_SYSTEM - -
- Coordinate system position BYTE Immediately
-
- 0 2 0 7 4/3 U
Description: The position of the coordinate system can be changed as follows:
291 CTM_CROSS_AX_DIAMETER_ON - -
- Diameter display active for transv. axes BYTE Immediately
-
- 0 1 0 1 4/3 U
Machine data
3.1 Display machine data
Parameter Manual
26 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
