Siemens SINUMERIK 808D ADVANCED Parameter Manual

3 Axis mode, MD34110 $MA_REFP_CYCLE_NR can be used to configure / deactivate forced
referencing on NC start
Corresponds with:
MD35030 $MA_SPIND_DEFAULT_ACT_MASK (activate spindle initial setting)
MD20700 $MC_REFP_NC_START_LOCK (NC start disable without reference point)
35030 SPIND_DEFAULT_ACT_MASK A06, A10 S1
- Time at which initial spindle setting is effective BYTE Reset
CTEQ
- - 0x00 0 0x03 2/2
Description: SPIND_DEFAULT_ACT_MASK specifies the time at which the operating mode defined in
MD35020 $MA_SPIND_DEFAULT_MODE becomes effective. The initial spindle setting can be
assigned the following values at the following points in time:
0 POWER ON
1 POWER ON and NC program start
2 POWER ON and RESET (M2/M30)
Special cases:
If MD35040 $MA_SPIND_ACTIVE_AFTER_RESET = 1, the following supplementary conditions
are applicable:
● SPIND_DEFAULT_ACT_MASK should be set to 0
● If this is not possible, the spindle must be at a standstill prior to activation.
Related to:
MD35020 $MA_SPIND_DEFAULT_MODE (initial spindle setting)
MD35040 $MA_SPIND_ACTIVE_AFTER_RESET (spindle active after reset)
35032 SPIND_FUNC_RESET_MODE A06, A10 -
- Reset response of individual spindle functions DWORD PowerOn
CTEQ
- - 0x00 0 0x01 1/1
Description: This data allows the "GWPS in every operating mode" function to be selected/deselected.
SPIND_FUNC_RESET_MODE, bit 0 = 0 : "GWPS in every operating mode" is deselected
SPIND_FUNC_RESET_MODE, bit 0 = 1 : "GWPS in every operating mode" is selected
35035 SPIND_FUNCTION_MASK A06, A10 K1, S1
- Spindle functions DWORD Reset
CTEQ
- - 0x510 0 0x7FFFFFFF 1/1
Description: This MD allows spindle-specific functions to be set.
The MD is bit-coded, the following bits are assigned:
Bit 0 = 1: Gear stage changes are suppressed with activated DryRun function for
block programming (M40, M41 to M45), programming via FC18,
and synchronized actions.
Bit 1 = 1: Gear stage changes are suppressed with activated program test function
for block programming (M40, M41 to M45), programming via
FC18, and synchronized actions.
Bit 2 = 1: Gear stage change for programmed gear stage will finally be carried
out after deselection of DryRun or program test functions with REPOS.
Bit 3: reserved
Bit 4 = 1:
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 269
