MD35500 $MA_SPIND_ON_SPEED_AT_IPO_START (feed enable for spindle in setpoint range)
35550 DRILL_VELO_LIMIT A06, A11, A04 -
rev/min Maximum speeds for tapping DOUBLE NEW CONF
CTEQ
- 6 10000., 10000.,
10000., 10000.,
10000., 10000.
0.1 - 1/1
Description: Limit speed values for tapping without compensating chuck with G331/G332.
The maximum speed of the linear motor characteristic range (constant acceleration
capacity) must be specified depending on the gear stage.
36000 STOP_LIMIT_COARSE A05 TE1, A3, B1, G2, S1, Z1
mm, degrees Exact stop coarse DOUBLE NEW CONF
-
808d-me42 - 0.04, 0.04, 0.04, 0.4 0.0 - 2/2
808d-me62 - 0.04, 0.04, 0.04, 0.4,
0.4
0.0 - 2/2
808d-te42 - 0.04, 0.04, 0.04, 0.4 0.0 - 2/2
808d-te62 - 0.04, 0.04, 0.04, 0.4,
0.4, 0.4
0.0 - 2/2
808d-mte40 - 0.04, 0.04, 0.04, 0.04,
0.04, 0.04, 0.04, 0.04...
0.0 - 2/2
808d-mte60 - 0.04, 0.04, 0.04, 0.04,
0.04, 0.04, 0.04, 0.04...
0.0 - 2/2
Description: Threshold for exact stop coarse
An NC block is considered as terminated if the actual position of the path axes is away
from
the setpoint
position by the value entered for the exact stop limit. If the actual
position of a path axis is not within this limit, the NC block is considered as not
terminated, and further part program execution is not possible. The magnitude of the
value entered influences the transition to the next block. The larger the value, the
earlier the block change is initiated.
If the specified exact stop limit is not reached, then
● the block is considered as not terminated,
● further traversing of the axis is not possible,
● alarm
25080 Positioning
monitoring is output after expiry of the time specified in
MD36020 $MA_POSITIONING_TIME (monitoring time for exact stop fine),
● the direction of movement +/- is indicated for the axis in the positioning display.
The exact stop window is also evaluated for spindles in position control mode (SPCON
instruction).
Special cases:
MD36000 $MA_STOP_LIMIT_COARSE must not be set smaller than MD36010 $MA_STOP_LIMIT_FINE
(exact stop fine). To achieve the identical block change behavior as with the "exact
stop
fine" criterion,
the exact stop coarse window may be identical to the exact stop
fine window. MD36000 $MA_STOP_LIMIT_COARSE must not be set equal to or greater than
MD36030 $MA_STANDSTILL_POS_TOL (standstill tolerance).
Related to:
MD36020 $MA_POSITIONING_TIME (delay time, exact stop fine)
36010 STOP_LIMIT_FINE A05 TE1, A3, B1, D1, G2, S1, Z1
mm, degrees Exact stop fine DOUBLE NEW CONF
-
808d-me42 - 0.01, 0.01, 0.01, 0.1 0.0 - 2/2
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 283
