Related to:
NC/PLC interface signal DB380x DBX1000.3 (2nd software limit switch plus)
36120 POS_LIMIT_MINUS2 A03, A05 TE1, A3, Z1
mm, degrees 2nd software limit switch minus DOUBLE NEW CONF
CTEQ
- - -1.0e8 - - 2/2
Description: Same meaning as 2nd software limit switch plus, but the traversing range limitation is
in the negative direction.
The PLC can select whether software limit switch 1 or 2 is to be active by means of
the interface signal.
For example:
DB380x DBX1000.2 = 0 (1st software limit switch minus) active for 1st axis
DB380x DBX1000.2 = 1 (2nd software limit switch minus) active for 1st axis
MD irrelevant:
if axis is not referenced.
Related to:
NC/PLC interface signal DB380x DBX1000.2 (2nd software limit switch minus)
36130 POS_LIMIT_PLUS2 A03, A05 TE1, A3, Z1
mm, degrees 2nd software limit switch plus DOUBLE NEW CONF
CTEQ
- - 1.0e8 - - 2/2
Description: This machine data can define a 2nd software limit switch position in the positive
direction in the machine axis system. The PLC can select which of the two software
limit switches 1 or 2 is to be active by means of an interface signal.
For example:
DB380x DBX1000.3 = 0 (1st software limit switch plus) active for 1st axis
DB380x DBX1000.3 = 1 (2nd software limit switch plus) active for 1st axis
MD irrelevant:
if axis is not referenced.
Related to:
NC/PLC interface signal DB380x DBX1000.3 (2nd software limit switch plus)
36200 AX_VELO_LIMIT A05, A11, A04 TE3, A3, G2, S1, V1
mm/min, rev/min Threshold value for velocity monitoring DOUBLE NEW CONF
CTEQ
808d-me42 6 11500., 11500.,
11500., 11500.,
11500., 11500.,
11500., 11500., ...
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-me62 6 11500., 11500.,
11500., 11500.,
11500., 11500.,
11500., 11500., ...
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te42 6 11500., 11500.,
11500., 11500.,
11500., 11500.,
11500., 11500., ...
(0./ 0.) (1.e300/ 1.e300) 2/2
Machine data
3.4 Axis-specific machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 287
