36060 STANDSTILL_VELO_TOL A05, A04 TE1, A2, A3, D1, Z1
mm/min, rev/min Threshold velocity/speed 'Axis/spindle in stop' DOUBLE NEW CONF
-
808d-me42 - 5.00, 5.00, 5.00,
1800.00
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-me62 - 5.00, 5.00, 5.00,
1800.00, 360.00
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te42 - 5.00, 5.00, 5.00,
1800.00
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te62 - 5.00, 5.00, 5.00,
1800.00, 360.00,
360.00
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-mte40 - (5.0/ 1.0), (5.0/ 1.0),
(5.0/ 1.0), (5.0/ 1.0),
(5.0/ 1.0), (5.0...
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-mte60 - (5.0/ 1.0), (5.0/ 1.0),
(5.0/ 1.0), (5.0/ 1.0),
(5.0/ 1.0), (5.0...
(0./ 0.) (1.e300/ 1.e300) 2/2
Description: This MD defines the standstill range for the axis velocity / spindle speed. If the
current actual velocity of the axis or the actual speed of the spindle is less than
the value entered in this MD, the NC/PLC interface signal DB390x DBX1.4 (Axis/spindle
stationary) is set.
To bring the axis/spindle to a standstill under control, the pulse enable should not
be removed until the axis/spindle is at a standstill. Otherwise the axis will coast
down.
Related to:
NC/PLC interface signal DB390x DBX1.4 (Axis/spindle stationary)
36100 POS_LIMIT_MINUS A03, A05, A11 TE1, R2, T1, A3, Z1
mm, degrees 1st software limit switch minus DOUBLE NEW CONF
CTEQ
- - -1.0e8 - - 2/2
Description: Same meaning as 1st software limit switch plus, however the traversing range
limitation is in the negative direction.
The MD becomes active after reference point approach if the NC/PLC interface signal
DB380x DBX1000.2 (2nd software limit switch minus) is not set.
MD irrelevant:
if axis is not referenced.
Related to:
NC/PLC interface signal DB380x DBX1000.2 (2nd software limit switch minus)
36110 POS_LIMIT_PLUS A03, A05, A11 TE1, R2, T1, G2, A3, Z1
mm, degrees 1st software limit switch plus DOUBLE NEW CONF
CTEQ
- - 1.0e8 - - 2/2
Description: A software limit switch can be activated in addition to the hardware limit switch. The
absolute position in
the machine axis system of the positive range limit of each axis
is entered.
The MD is active after reference point approach if NC/PLC interface signal DB380x
DBX1000.3 (2nd software limit switch plus) has not been set.
MD irrelevant:
if axis is not referenced.
Machine data
3.4 Axis-specific machine data
Parameter Manual
286 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
