Siemens SINUMERIK 808D ADVANCED Parameter Manual

41110 JOG_SET_VELO - H1
mm/min Axis velocity in JOG DOUBLE Immediately
-
- - 0.0 0.0 - 7/7 U
Description: Value not equal to 0:
The velocity value entered applies to linear axes traversed in JOG mode if linear
feedrate (G94) is active for the relevant axis (SD41100 $SN_JOG_REV_IS_ACTIVE = 0).
The axis velocity is active for
● continuous jogging
● incremental jogging (INC1, ... INCvar)
● handwheel traversing.
The value entered is valid for all linear axes and must not exceed the maximum
permissible axis velocity (MD32000 $MA_MAX_AX_VELO).
In the case of DRF, the velocity defined by SD41110 $SN_JOG_SET_VELO is reduced by
MD32090 $MA_HANDWH_VELO_OVERLAY_FACTOR.
Value = 0:
If 0 has been entered in the setting data, the active linear feedrate in JOG mode is
MD32020 $MA_JOG_VELO "Jog axis velocity". Each axis can be given its own JOG velocity
with this MD (axial MD).
SD irrelevant for ......
● Linear axes if SD41100 $SN_JOG_REV_IS_ACTIVE = 1
● Rotary axes (SD41130 $SN_JOG_ROT_AX_SET_VELO is active here)
Application example(s)
The operator can thus define a JOG velocity for a specific application.
Related to ....
SD41100 $SN_JOG_REV_IS_ACTIVE (revolutional feedrate with JOG active)
Axial MD32020 $MA_JOG_VELO (JOG axis velocity)
Axial MD32000 $MA_MAX_AX_VELO (maximum axis velocity)
Axial MD32090 $MA_HANDWH_VELO_OVERLAY_FACTOR (ratio of JOG velocity to handwheel
velocity (DRF))
SD41130 $SN_JOG_ROT_AX_SET_VELO (JOG speed with rotary axes)
41120 JOG_REV_SET_VELO - H1
mm/rev Revolutional feedrate of axes in JOG mode DOUBLE Immediately
-
808d-me42 - 0.0 0.0 - 1/1 M
808d-me62 - 0.0 0.0 - 1/1 M
808d-te42 - 0.0 0.0 - 1/1 M
808d-te62 - 0.0 0.0 - 1/1 M
808d-mte40 - 0.0 0.0 - 7/7 U
808d-mte60 - 0.0 0.0 - 7/7 U
Description: Value not equal to 0:
The velocity value entered applies to axes traversed in JOG mode if revolutional
feedrate (G95) is active for the relevant axis (SD41100 $SN_JOG_REV_IS_ACTIVE = 1).
The axis velocity is active for
● continuous jogging
● incremental jogging (INC1, ... INCvar)
● handwheel traversing. The value entered is valid for all axes and must not exceed
the maximum permissible axis velocity (MD32000 $MA_MAX_AX_VELO).
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 303
