SD irrelevant for ......
Application example(s). The operator can thus define a JOG speed for the spindles for
a specific application.
Related to ....
Axial MD32020 $MA_JOG_VELO (JOG axis velocity)
MD35130 $MA_GEAR_STEP_MAX_VELO_LIMIT (maximum speeds of the gear stages)
41300 CEC_TABLE_ENABLE - K3
- Compensation table enable BOOLEAN Immediately
-
808d-me42 6 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-me62 8 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-te42 6 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-te62 8 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-mte40 6 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
808d-mte60 8 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
Description: 1: The evaluation of the compensation table [t] is enabled.
The compensation table is now included in the calculation of the compensation value
for the compensation axis.
The compensation axis $AN_CEC_OUTPUT_AXIS can be taken from the table configuration.
The effective total compensation value in the compensation axis can be adapted to the
current machining by the targeted activation of tables (from NC part programm or PLC
user program).
The function does not become active until the following conditions have been fulfilled:
● The option "Interpolatory compensation" is set
● The associated compensation tables in the NC user memory have been loaded and
enabled (SD41300 $SN_CEC_TABLE_ENABLEt] = 1)
● The
current position
measuring system is referenced (NC/PLC interface signal DB390x
DBX0.4 / .5 (Referenced/synchronized 1 or 2) = 1).
0: The evaluation of the sag compensation table [t] is not enabled.
Related to ....
MD18342 $MN_MM_CEC_MAX_POINTS[t] Number of interpolation points with sag
compensation
SD41300 $SN_CEC_TABLE_ENABLE[t] Evaluation of the sag compensation table t is
enabled
NC/PLC interface signal DB390x DBX0.4 (Referenced/synchronized 1)
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 305
