Note: The block content corresponds to "WAITM( 101, 1,3,5,7)", the user does not see
this block content, he sees REPOSA!
Note:
SERUPRO_SYNC_MASK is evaluated as soon as the part program command REPOSA is
interpreted.
SERUPRO_SYNC_MASK can still be changed if SERUPRO is in the state "search target
found".
If REPOSA has already been executed, a change to SERUPRO_SYNC_MASK can only become
active if a new REPOS is set. This occurs, for example, by:
● Starting a new ASUB.
● STOP-JOG-AUTO-START
● STOP - select a new REPOS mode RMI/RMN/RME/RMB - START
Note:
If one uses the prog. event for search and if the NCK is at alarm 10208 then a change
of SERUPRO_SYNC_MASK is not active unless one sets a new REPOS.
SERUPRO_SYNC_MASK == 0 A block is NOT inserted.
Note:
If the bit for the current channel is not set in SD42125 $SC_SERUPRO_SYNC_MASK then a
block is NOT inserted.
Example:
If SD42125 $SC_SERUPRO_SYNC_MASK= 0xE is programmed in channel 1, then a block is NOT
inserted.
This assignment is reserved for a future function!
42140 DEFAULT_SCALE_FACTOR_P - FBFA
- Default scaling factor for address P DWORD Immediately
-
- - 1, 1, 1, 1, 1, 1, 1, 1... - - 7/7 U
Description: The value in this machine data is active if no scaling factor P has been programmed in
the block.
Related to:
WEIGHTING_FACTOR_FOR_SCALE
42150 DEFAULT_ROT_FACTOR_R - -
- Default rotation factor for address R DOUBLE Immediately
-
- - 0., 0., 0., 0., 0., 0., 0.,
0....
- - 7/7 U
Description: The value in this machine data is active if no factor for rotation R is programmed in
the block.
42160 EXTERN_FIXED_FEEDRATE_F1_F9 - FBFA
- Fixed feedrates F1 - F9 DOUBLE Immediately
-
808d-me42 10 0., 0., 0., 0., 0., 0., 0.,
0., 0., 0., 0., 0., 0., 0.,
0., 0., ...
0.0 - 0/0 S
808d-me62 10 0., 0., 0., 0., 0., 0., 0.,
0., 0., 0., 0., 0., 0., 0.,
0., 0., ...
0.0 - 0/0 S
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 311
