Siemens SINUMERIK 808D ADVANCED Parameter Manual

808d-me62 - 36.0, 36.0, 36.0, 36.0,
36.0, 36.0, 36.0, 36.0...
0.0 89.0 0/0 S
808d-te42 - 36.0, 36.0, 36.0, 36.0,
36.0, 36.0, 36.0, 36.0...
0.0 89.0 0/0 S
808d-te62 - 36.0, 36.0, 36.0, 36.0,
36.0, 36.0, 36.0, 36.0...
0.0 89.0 0/0 S
808d-mte40 - 36.0, 36.0, 36.0, 36.0,
36.0, 36.0, 36.0, 36.0...
0.0 89.0 7/7 U
808d-mte60 - 36.0, 36.0, 36.0, 36.0,
36.0, 36.0, 36.0, 36.0...
0.0 89.0 7/7 U
Description: The setting data defines the limit angle from which the compressor COMPCAD interprets
a block transition
as a corner. Practical values lie between 10 and 40 degrees. Values
from 0 to 89 degrees inclusive are permitted.
The angle only serves as an approximate measure for corner detection. The compressor
can also classify
flatter block transitions as corners and eliminate larger angles as
outliers on account of plausibility considerations.
42471 MIN_CURV_RADIUS EXP, C09 -
mm Minimum radius of curvature DOUBLE Immediately
-
808d-me42 - 3.0, 3.0, 3.0, 3.0, 3.0,
3.0, 3.0, 3.0...
0.0 - 0/0 S
808d-me62 - 1.0 0.0 - 2/2 M
808d-te42 - 3.0, 3.0, 3.0, 3.0, 3.0,
3.0, 3.0, 3.0...
0.0 - 0/0 S
808d-te62 - 3.0, 3.0, 3.0, 3.0, 3.0,
3.0, 3.0, 3.0...
0.0 - 0/0 S
808d-mte40 - 3.0, 3.0, 3.0, 3.0, 3.0,
3.0, 3.0, 3.0...
0.0 - 7/7 U
808d-mte60 - 3.0, 3.0, 3.0, 3.0, 3.0,
3.0, 3.0, 3.0...
0.0 - 7/7 U
Description: The setting data defines a typical tool radius. It is only evaluated in compressor
COMPCAD. The lower the value, the greater the precision, but the slower the program
execution.
42472 MIN_SURF_RADIUS EXP, C09 -
mm Minimum curvature radius for COMPSURF
[0] Minimum curvature radius for geometry axes
[1] Minimum curvature radius for the orientation axes
[2] Minimum curvature radius for other axes
DOUBLE Immediately
-
808d-me42 3 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0,...
0.0 - 0/0 S
808d-me62 3 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0,...
0.0 - 2/2 M
808d-te42 3 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0,...
0.0 - 0/0 S
808d-te62 3 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0,...
0.0 - 0/0 S
NC setting data
Parameter Manual
316 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
