42465 SMOOTH_CONTUR_TOL - B1
mm Maximum contour tolerance on smoothing DOUBLE Immediately
-
808d-me42 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 0/0 S
808d-me62 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 0/0 S
808d-te42 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 0/0 S
808d-te62 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 0/0 S
808d-mte40 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 7/7 U
808d-mte60 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 999999. 7/7 U
Description: This setting data defines the maximum tolerance for smoothing the contour.
Related to:
MD20480 $MC_SMOOTHING_MODE,
SD42466 $SC_SMOOTH_ORI_TOL
42466 SMOOTH_ORI_TOL - B1
degrees Maximum deviation of tool orientation during smoothing. DOUBLE Immediately
-
808d-me42 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 0/0 S
808d-me62 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 0/0 S
808d-te42 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 0/0 S
808d-te62 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 0/0 S
808d-mte40 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 7/7 U
808d-mte60 - 0.05, 0.05, 0.05, 0.05,
0.05, 0.05, 0.05, 0.05...
0.000001 90. 7/7 U
Description: This setting data defines the maximum tool orientation tolerance during smoothing.
The data determines the maximum permissible
angular displacement of the tool orientation.
This data only applies if an orientation tranformation
is active.
Related to:
MD20480 $MC_SMOOTHING_MODE,
SD42465 $SC_SMOOTH_CONTUR_TOL
42470 CRIT_SPLINE_ANGLE - W1, PGA
degrees Corner limit angle for compressor DOUBLE Immediately
-
808d-me42 - 36.0, 36.0, 36.0, 36.0,
36.0, 36.0, 36.0, 36.0...
0.0 89.0 0/0 S
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 315
