SD = FALSE: Incremental value is added to current actual value
The setting data is evaluated on NC start for output of the action blocks.
42450 CONTPREC - B1, K6
mm Contour accuracy DOUBLE Immediately
-
808d-me42 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.000001 999999. 0/0 S
808d-me62 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.000001 999999. 0/0 S
808d-te42 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.000001 999999. 0/0 S
808d-te62 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.000001 999999. 0/0 S
808d-mte40 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.000001 999999. 7/7 U
808d-mte60 - 0.1, 0.1, 0.1, 0.1, 0.1,
0.1, 0.1, 0.1...
0.000001 999999. 7/7 U
Description: Contour accuracy. This setting data can be used to define the accuracy to be maintained
for the path
of the geometry axes on curved contours. The lower the value and the lower
the servogain factor of the geometry axes, the greater the reduction of path feed on
curved contours.
Related to ....
MD20470 $MC_CPREC_WITH_FFW
SD42460 $SC_MINFEED
42460 MINFEED - B1, K6
mm/min Minimum path feedrate for CPRECON DOUBLE Immediately
-
808d-me42 - 1., 1., 1., 1., 1., 1., 1.,
1....
1.e-6 1.e9 0/0 S
808d-me62 - 1., 1., 1., 1., 1., 1., 1.,
1....
1.e-6 1.e9 0/0 S
808d-te42 - 1., 1., 1., 1., 1., 1., 1.,
1....
1.e-6 1.e9 0/0 S
808d-te62 - 1., 1., 1., 1., 1., 1., 1.,
1....
1.e-6 1.e9 0/0 S
808d-mte40 - 1., 1., 1., 1., 1., 1., 1.,
1....
1.e-6 1.e9 7/7 U
808d-mte60 - 1., 1., 1., 1., 1., 1., 1.,
1....
1.e-6 1.e9 7/7 U
Description: Minimum path feedrate with the "Contour accuracy" function active. The feedrate is not
limited to below this value unless a lower F value has been programmed or the axis
dynamics do not permit it.
Related to ....
MD20470 $MC_CPREC_WITH_FFW
SD42450 $SC_CONTPREC
NC setting data
Parameter Manual
314 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
