Internal machining is performed. The circle radius in SD42691 $SC_JOG_CIRCLE_RADIUS is
the maximum possible radius.
Bit 2 = 1 :
External machining is performed. The circle radius in SD42691 $SC_JOG_CIRCLE_RADIUS
is the minimum possible radius.
Bit 3 = 0 :
Given a full circle, the radius is enlarged starting from the circle center point in
the direction of the ordinate (2nd geometry axis) of the plane.
Bit 3 = 1 :
Given a full circle, the radius is enlarged starting from the circle center point in
the direction of the abscissa (1st geometry axis) of the plane.
This setting data should be written via the user interface.
42693 JOG_CIRCLE_START_ANGLE - -
degrees Circle start angle DOUBLE Immediately
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 2/2 M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 2/2 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 2/2 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 2/2 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 7/7 U
Description: This setting data defines the start angle during JOG of circles.
The start angle refers to the abscissa of the current plane. Traversing is only
possible within the range
between the start and the end angle. SD42692 $SC_JOG_CIRCLE_MODE bit 0 defines the
direction from the start to the end angle. If start and end angle equal zero, no
limitation is active.
This setting data is written via the user interface.
42694 JOG_CIRCLE_END_ANGLE - -
degrees Circle end angle DOUBLE Immediately
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 2/2 M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 2/2 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 2/2 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 2/2 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 360 7/7 U
Description: This setting data defines the end angle during JOG of circles.
The end angle refers to the abscissa of the current plane. Traversing is only possible
within the range
between the start and the end angle. SD42692 $SC_JOG_CIRCLE_MODE bit 0 defines the
direction from the start to the end angle. If start and end angle equal zero, no
limitation is active.
This setting data is written via the user interface.
42700 EXT_PROG_PATH - K1
- Program path for external subroutine call EXTCALL STRING Immediately
-
808d-me42 - - - - 3/3 U
NC setting data
Parameter Manual
328 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
